42
VQT2T11
Specifications
Signal system: PAL/NTSC
Operating temperature range:
i5 oC to i35 oC
Operating humidity range:
10 % to 80 % RH (no condensation)
Video output: 1.0 Vp-p (75 ≠)/Pin jack :1 system
Component video output (Y: green, P
B
: blue
,
P
R
: red):
Y :1.0 Vp-p (75 ≠)/P
B
, P
R
: 0.7 Vp-p (75 ≠)/
Pin jack:1 system
Audio output: 2 Vrms (1 kHz, 0 dB)/Pin jack
Number of connectors :
7.1 channel discrete output:1 system
(2 channel + 5.1 channel discrete output)
Digital audio output:
Optical digital output : Optical terminal
Coaxial digital output : Pin jack
HDMI AV output: Type A (19 pin) : 2 systems(Main/Sub)
HDMI (V.1.4 with 3D, Content Type)
This unit supports “HDAVI Control 5” function.
SD card slot: Connector : 1 system
USB slot: USB2.0 : 2 systems
Ethernet: 10BASE-T/100BASE-TX:1 system
LASER Specification
Class 1 LASER Product:
Wave length:790 nm (CDs)/650 nm (DVDs)/405 nm (BDs)
Laser power: No hazardous radiation is emitted with the
safety protection
Power supply: AC 220 to 240 V, 50 Hz
Power consumption: Approx. 32 W
Power consumption in standby mode: Approx. 0.2 W
Power consumption in quick start standby mode: Approx. 8.1 W
Dimensions (WkDkH) : Including the projecting parts
430 mmk245 mmk66 mm
Mass: Approx. 2.6 kg
\For\the\United\Kingdom,\Continental\Europe\and\Republic\of\Ireland\
Wireless LAN Adaptor (DY-WL10)
Dimensions (WkDkH)
44 mmk72 mmk27 mm
Mass: Approx. 29 g
Antenna: Tx 1, Rx 2
Interface: USB2.0
Standard Compliance:
IEEE802.11n / IEEE802.11a / IEEE802.11g / IEEE802.11b
Transmission system:
MISO-OFDM system, OFDM system, DSSS system
Frequency Range:
IEEE802.11n / IEEE802.11a:
5.15 GHz - 5.35 GHz / 5.47 GHz - 5.725 GHz
IEEE802.11g / IEEE802.11b / IEEE802.11n:
2.4 GHz - 2.4835 GHz
Transfer rate (standard)*:
IEEE802.11n: Tx Max. 150 Mbps, Rx Max. 300 Mbps
IEEE802.11g / IEEE802.11a: Max. 54 Mbps
IEEE802.11b: Max. 11 Mbps
Access Mode: Infrastructure mode
Security: WPA2-PSK (TKIP/AES)
WPA-PSK (TKIP/AES)
WEP (64 bit / 128 bit)
(This unit supports WPA and WPA2 encryption.)
* Transfer rates are theoretical values; however, actual
communication rate will vary according to communication
environment or connected equipment.
Specifications are subject to change without notice.
Declaration of Conformity (DoC)
Hereby, “Panasonic Corporation” declares that this product
is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
Customers can download a copy of the original DoC to our
R&TTE products from our DoC server:
http://www.doc.panasonic.de
Contact in the EU: Panasonic Services Europe, a Division of
Panasonic Marketing Europe GmbH,
Panasonic Testing Centre, Winsbergring 15, 22525
Hamburg, Germany
This product is intended to be used in the following
countries.
Austria, Belgium, Bulgaria, Cyprus, Czech Republic,
Denmark, Finland, France, Germany, Greece, Hungary,
Ireland, Italy, Iceland, Liechtenstein, Luxembourg, Malta,
Netherlands, Norway, Poland, Portugal, Romania, Slovakia,
Slovenia, Spain, Sweden, United Kingdom, Switzerland
This product is intended for general consumer. (Category 3)
The WLAN feature of this product shall exclusively be used
inside buildings.
This product on purpose to connect to access point of
2.4 GHz or 5 GHz WLAN.
Product Identification Marking is located on the bottom of
adaptor.
