Make sure that all accessories shown below were
provided and have not been damaged. Report
damage or shortages to the reseller from which the
units were purchased. Page 3 includes an area for
recording important information such as the name of
reseller, serial number, and date of purchase.
Note:
B
Save the original carton and packing materials for
future shipping and transporting of the unit. They
have been specifically designed to protect the
equipment during shipment.
Unpacking
Toner cartridges
(black, cyan, magenta, and
yellow)
(see page 10)
Power cord (see page 11)
Color Calibration Card
(see page 21)
KX-P8415 CD-ROM
(includes printer driver,
manuals and Acrobat
Reader program
(see page 13, 14)
Setup Guide and
Reference Guide
Part Names
Front side view
Rear side view
#
$
Printer panel
%
&
'
(
Fuser unit
)
Color imaging unit (see page 10)
*
$
%
&
'
(
)
*
#
Multi-purpose tray (MPT) [see page 19]
$
Left side door [Media thickness switch is
accessible by opening the left side door
(see page 19)]
%
Parallel interface connector (see page 11)
&
'
&
%
$
#
'
Supplement
(for model numbers of
supplies)
Before
You
Start
Setup
Guide
#
