6 Put filter 3 (activated carbon filter) back into the appliance.
Note: Make sure that the side with the tag points towards you.
7 Put filter 2 (multi-care filter) back into the appliance.
Note: Make sure that the side with the tag points towards you.
8 Put filter 1 (pre-filter) back into the appliance.
Note: Make sure that the side with the two projections points towards you.
Note: Make sure that all hooks are properly attached to the appliance.
9 To reattach the front panel, insert the two hooks at the bottom of
the front panel into the openings at the bottom of the appliance first
(1). Then push the panel against the body of the appliance (2).
Note: Make sure you align the hooks of the front panel properly onto the
bottom of the appliance. Otherwise you cannot close the front panel properly.
Preparing for humidification
1 Slide the water bucket cover at the back of the appliance to the left
(1) and remove it from the appliance (2).
2
1
1
2
English 11
