Premier Mounts PP-FCTA-QL User Manual
Page 9
Installation
Instructions
Page
9
Braided
Cable
T-Bar
Frame
Ceiling
Tile
Quick
Lock
PP-FCTA-QL
Step 1. Thread each braided cable through the Quick Lock, the mounting hole in the corner of ceiling mount, and then completely
through the opposite side of the Quick Lock to secure.
Step 2. Adjust the braided cable tension. but do not overtighten.
Step 3. When adjusting the tension of the weight-bearing side of the Quick Lock, the cable must be pulled through the Quick Lock until
the desired tension is attained. Once attained, pull the braided cable through the other side of the Quick Lock.
Step 4. Once the tension has been adjusted, be sure that there is at least 6” of excess braided cable on the non-weight bearing side of the
Quick
Lock.
Step 5. Use cable cutters to remove any remaining braided cable (optional).
To relieve tension on the braided cable, slide the release pin on the Quick Lock.
6” Excess-
Braided
Cable
