Page 7
6
Picture 4. WLAN Mini PCI Adapter and Antenna
Note: The WLAN card has 2 connectors: MAIN and AUX. Please be sure to connect the
antenna to the MAIN connector when re-assembling the WLAN card!
Keyboard
To remove the keyboard, perform the following steps:
1. Remove the 3 screws located in the battery compartment (
2. Push up the keyboard cover in the area indicated with the 2 arrows in
.
3. Remove the 3 screws securing the keyboard shown in
.
4. Gently lift out the keyboard.
5. To disconnect the flat cable, loosen the clip and slide out the cable (
Picture 5. Battery Compartment
Picture 6. Keyboard Cover Removed
