Picture 2. Power Cable of Heat Sink Assembly

Picture 3. Heat Sink Assembly Screws

WiFi LAN Adapter (Mini PCI)

To remove the Wireless LAN Adapter (mini PCI), perform the following steps:

1. Remove the bottom cover (5 screws marked B on

Picture 1

).

2. Push the clips securing the card sideways; the card will ‘

eject’

.

3. Disconnect the WLAN antenna (see

Picture 4

).

4. Lift out the mini PCI card.
