12
Picture 16. LCD Bezel
Inverter Board
To remove the inverter board, perform the following steps:
1. Unplug the cable on the inverter board.
2. Remove the screw (screw A in
Picture 17 ).
3. Take away the inverter board.
Picture 17. LCD Assembly Without Bezel
LCD Panel
To remove the LCD panel, perform the following steps:
1. Remove the 4 screws holding the hinges (marked B in Picture 17 ).
2. Remove 2 screws holding the LCD panel brackets (indicated with C in Picture 17 ,
you only need to remove the screws in the middle).
