Philips FW-P900 - Manual (Page 30)

30
English
3139 115 20411
Specifications
AMPLIFIER
Output power
Total power ........................................................... 300 W
DPL Mode
Left/Right Channel .................. 2 x 80 W RMS (1)
Center Channel ....................... 50 W RMS, 12
Ω
Surround Channel ............ 2 x 25 W RMS, 6 Ω
Stereo Mode ............................... 2 x 80 W RMS (1) /
..................................................................... 2 x 70 W FTC
Signal-to-noise ratio .......................... ≥ 75 dBA (IEC)
Frequency response ......... 40 – 20000 Hz, ± 3 dB
Input sensitivity
AUX In / CDR/DVD In .................... 500 mV / 1V
Output
Speakers .................................................................... ≥ 6 Ω
Center Speaker .................................................. ≥ 12 Ω
Surround Speakers .............................................. ≥ 6 Ω
Headphones ...................................... 32 Ω – 1000 Ω
Subwoofer Out .............. 1.5 V ±2dB, > 22000 Ω
Line Out ...................... 500 mV ±2dB, > 22000 Ω
Digital Out .................................... IEC 958, 44.1 kHz
Surround Out (wireless) ............................. 350 mV
(1) (6 Ω, 60 Hz – 12.5 kHz, 10% THD)
CD PLAYER SECTION
Number of programmable tracks ......................... 40
Frequency response .......................... 40 – 20000 Hz
Signal-to-noise ratio .......................................
≥ 76 dBA
Channel separation .......................... ≥ 79 dB (1 kHz)
Total harmonic distortion ............ < 0.02% (1 kHz)
TUNER SECTION
FM wave range ................................... 87.5 – 108 MHz
AM wave range .................................. 530 – 1700 kHz
Number of presets ........................................................ 40
Antenna
FM ............................................... 300
Ω dipole wire
AM ........................................................ Loop antenna
TAPE PLAYER SECTION
Frequency response
CrO
2
tape (type II) .......... 60 – 15000 Hz (5 dB)
Normal tape (type I) ...... 60 – 15000 Hz (5 dB)
Signal-to-noise ratio
CrO
2
tape (type II) ..................................... ≥ 50 dBA
Normal tape (type I) ................................. ≥ 47 dBA
Wow and flutter ......................................... ≤ 0.4% DIN
SPEAKERS SYSTEM
Front left/right
System .............................. shielded 3 way, Bass reflex
Impedance ........................................................................ 6
Ω
Woofer ................................................ 1 x 6.5" full range
Tweeter ............................................... 1 x 2.5" Ferrofluid
Dimensions (w x h x d) . 240 x 310 x 290 (mm)
............................................. 9.45 x 12.20 x 11.42 (inch)
Weight ................. 4.9 kg each / 10.80 pounds each
Surround speakers
System ......................................................... closed satellite
Impedance ........................................................................ 6
Ω
Speaker Driver .................................... 1 x 4” full range
Dimensions (w x h x d) . 235 x 135 x 155 (mm)
.................................................. 9.21 x 5.31 x 6.10 (inch)
Weight ................. 1.07 kg each / 2.36 pounds each
Center speaker
System .............................................. shielded bass reflex
Impedance ..................................................................... 12
Ω
Speaker Driver .................................... 1 x 4” full range
Dimensions (w x h x d) . 235 x 135 x 155 (mm)
.................................................. 9.21 x 5.31 x 6.10 (inch)
Weight ......................................... 1.21 kg / 2.67 pounds
SW-900 SUBWOOFER
System ................................................. Active Subwoofer
(non magnetically shielded design)
Subwoofer ......................................................................... 6.5"
Output Power ........................ 50 W RMS
(4 Ω, DIN)
THD ............................................................. 10 % at 55 Hz
Reproduction frequency response ... 45 – 150 Hz
Phase switch ............................................................ 0˚, 180˚
Input sensitivity (Subwoofer In) .......... 460 mVrms
AC Power ................................................... 120 V / 60 Hz
Power consumption . 40 W (at 1/8 Rated Power)
Dimensions (w x h x d) . 200 x 310 x 370 (mm)
.............................................. 7.87 x 12.20 x 14.57 (inch)
Weight ............................. 6.8 kg each / 15.00 pounds
GENERAL
Material/finish ................................... Polystyrene/Metal
AC Power ................................................... 120 V / 60 Hz
Power Consumption
Active ...................................................................... 140 W
Standby ................................................................. < 20 W
Eco Power Standby ........................................... < 2 W
Dimensions (w x h x d) .. 265 x 310 x 390 (mm)
............................................ 10.43 x 12.20 x 15.35 (inch)
Weight (without speakers) 8.7 kg / 19.18 pounds
Specifications and external appearance are
subject to change without notice.
