65
Jams
For fax advantage assistance, call 1-800-435-7329.
Recording paper jam !
1 Open the cover by pressing the cover open
button.
2 Remove the film cartridge.
3 Remove the jammed recording paper.
5 Turn the film cartridge over so that the
“BACK” is facing up.
6 Replace the film cartridge by first placing the
front of the cartridge into the unit and then
lowering the “BACK” of the cartridge into
place.
7 Close the cover securely by pushing down
on the dotted area at both ends.
4 If the ink film is slack, turn the film cartridge
over and tighten it by winding the gears.
If the unit does not eject any recording paper during reception or copying, the recording paper
has jammed.
When paper has jammed under the film cartridge
The display will show the following.
Display: PAPER 1 JAMMED
Cover open
button
Film cartridge
Cover open
button
Gears
BA
CK
Film
cartridge
Incorrect Correct
Tight
