Reference
Specifications
VIDEO SECTION
Video system
Signal system NTSC
Composite video output
Output level 1 Vp-p (75 Ω )
Terminal Pin jack (1 system)
S-video output
Y output level 1 Vp-p (75 Ω )
C output level NTSC; 0.286 Vp-p (75
Ω
)
Terminal S terminal (1 system)
Component video output (480P/480I)
Y output level 1 Vp-p (75 Ω )
P
B
output level 0.7 Vp-p (75 Ω )
P R output level 0.7 Vp-p (75
Ω
)
Terminal Pin jack (Y: green, P B : blue, P R : red) (1 system)
SPEAKER SECTION
Front/Surround speakers SB-FS670
Type 1 way, 1 speaker system (Bass reflex)
Speaker unit(s)
1 Full range 6.5 cm (2 1 / 2 ˝) Cone type
Impedance 6 Ω
Input power (IEC) 55 W (Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 65 Hz–22 kHz (–16 dB)
90 Hz–20 kHz (–10 dB)
Dimensions (WxHxD) 88 x 194 x 118 mm
(3
15 / 32 ˝ x 7 5 / 8 ˝ x 4 21 / 32 ˝)
Mass 0.78 k g (1.72 Ibs)
Center speaker SB-PC670
Type 2 Way, 3 speaker system (Bass reflex)
Speaker unit(s)
2 Full range 6.5 cm (2 1 /
2
˝) Cone type
1 Super tweeter Piezo type
Impedance 6
Ω
Input power (IEC) 160 W (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 10 kHz
Frequency range 85 Hz–22 kHz (–16 dB)
100 Hz–20 kHz (–10 dB)
Dimensions (WxHxD) 430 x 88 x 115 mm
(16 15 / 16 ˝ x 3 15 / 32 ˝ x 4 17 / 32 ˝)
Mass 1.54 k g (3.4 Ibs)
Subwoofer SB-W670
Type 1 Way, 1 speaker system (Bass reflex)
Speaker unit(s)
1 Woofer 17 cm (6 3 / 4 ˝) Cone type
Impedance 4 Ω
Input power (IEC) 220 W (Max)
Output sound pressure 81 dB/W (1.0 m)
Frequency range 40 Hz–1 kHz (–16 dB)
45 Hz–900 Hz (–10 dB)
Dimensions (WxHxD) 269 x 287 x 282 mm
(10 19 / 32 ˝ x 11 5 / 16 ˝ x 11 3 / 32 ˝)
Mass 3.96 k g (8.73 Ibs)
GENERAL
Power supply AC 120 V, 60 Hz
Power consumption 280 W
Dimensions (WxHxD) 430 x 105 x 372.6 mm
(16 15 / 16 ˝ x 4 1 / 8 ˝ x 14 11 / 16 ˝)
Mass 7.6 k g (16.75 Ibs)
Operating temperature range +5°C to +35°C (+41°F to +95°F)
Operating humidity range 5 % to 90 % RH (no condensation)
Power consumption in standby mode: 0.5 W
Note
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by a digital spectrum
analyzer.
AMPLIFIER SECTION
RMS Output Power: Dolby Digital Mode
Front Ch 55 W per channel (6
Ω
), 1 kHz, 10 % THD
Surround Ch 55 W per channel (6
Ω
), 1 kHz, 10 % THD
Center Ch 160 W per channel (6 Ω ), 1 kHz, 10 % THD
Subwoofer Ch 220 W per channel (4 Ω ), 100 Hz, 10 % THD
Total RMS Dolby Digital mode Power 600 W
FTC Output Power: Dolby Digital Mode
Front Ch 35 W per channel (6 Ω ), 120 Hz–20 kHz, 1 % THD
Surround Ch 35 W per channel (6 Ω ), 120 Hz–20 kHz, 1 % THD
Center Ch 110 W per channel (6
Ω
), 120 Hz–20 kHz, 1 % THD
Subwoofer Ch 140 W per channel (4 Ω ), 45 Hz–120 Hz, 1 % THD
Total FTC Dolby Digital mode power 390 W
FM/AM TUNER, TERMINALS SECTION
Preset station FM 15 stations
AM/MW 15 stations
Frequency Modulation (FM)
Frequency range 87.9 –107.9 MHz (200 kHz step)
87.5 –108.0 MHz (100 kHz step)
Sensitivity 2.5 µV (IHF)
S/N 26 dB 2.2 µV
Antenna terminals 75
Ω
(unbalanced)
Amplitude Modulation (AM/MW)
Frequency range 520–1710 kHz (10 kHz step)
AM Sensitivity S/N 20 dB at 1000 kHz 560 µV/m
Phone jack
Terminal Stereo 3.5 mm ( 1 /
8
˝) jack
DISC SECTION
Discs played [8 cm (3˝) or 12 cm (5˝)]
(1) DVD-RAM (DVD-VR compatible, JPEG formatted disc)
(2) DVD-Audio
(3) DVD-Video
(4) DVD-R (DVD-Video compatible)
(5) CD-Audio (CD-DA)
(6) Video CD
(7) SVCD (Conforming to IEC62107)
(8) CD-R/RW (CD-DA, Video-CD, SVCD, MP3, WMA, JPEG
formatted disc)
(9) MP3/WMA 1
¡ Compatible compression rate:
MP3: between 32 kbps and 320 kbps
WMA: between 48 kbps and 320 kbps
(10) JPEG 1
¡ Exif Ver 2.1 JPEG Baseline files
¡ Picture resolution: between 320 x 240 and 6144 x 4096 pixels
(Sub sampling is 4:2:2 or 4:2:0)
(11) HighMAT Level 2 (Audio and Image)
1 The total combined maximum number of recognizable audio
and picture contents and groups: 4000 audio and picture
contents and 400 groups.
Pickup
Wavelength
DVD 662 nm
CD 785 nm
Laser power CLASS II a/CLASS I
CLASS 2/CLASS 3A
Audio output (DISC)
Number of channels 5.1 ch (FL, FR, C, SL, SR, SW)
Audio performance (measured at LINE OUT terminal)
Frequency response
DVD (linear audio) 4 Hz–22 kHz (48 kHz sampling)
4 Hz–44 kHz (96 kHz sampling)
DVD-Audio 4 Hz–88 kHz (192 kHz sampling)
CD-Audio 4 Hz–20 kHz
S/N ratio
CD-Audio 95 dB
Dynamic range
DVD (linear audio) 95 dB
CD-Audio 93 dB
Total harmonic distortion
CD-Audio 0.005 %
