Other functions
Operating other equipment
Connection example
PLAY OUT
R
L
REC IN
R
L
AUDIO OUT
R
L
VIDEO IN
2
1
VIDEO OUT AUDIO OUT
R
L
To play sound from your
television
Reduce the volume on the
television to minimum and control
the volume on this unit.
To show the video from the
video cassette recorder
Select “VIDEO 2” input on
your television in this example.
To play sound from
a tape deck
To record discs, the
radio, etc. to a tape deck
To play sound from a
video cassette recorder
Already connected
(
A page 7)
Audio cable (not included)
Video cable (not included)
: Signal flow
Television
(not included)
Video cassette recorder
(not included)
Tape deck
(not included)
