41
Specifications
[GENERAL]
Supply voltage: AC 120V ±10%, 50/60 Hz
Power consumption: 93 W
DC supply voltage: 12 V
DC power input current: 6.2 A
Ambient operating temperature
41°F to 104°F (5°C to 40°C)
Ambient operating humidity
10% to 85% (no condensation)
Weight
17.16 lb (7.8 kg)
Dimensions (WaHaD)
8 7 / 16 ˝a5 1 / 4 ˝a16 15 / 16 ˝ (214a132a430 mm)
Recording format
DVCPRO50 format/DVCPRO format switchable
Recording video signals
525i
Recording audio signals
O
DVCPRO50: 48 kHz, 16 bits, 4 channels
O
DVCPRO: 48 kHz, 16 bits, 2 channels
Recording tracks
O
Digital video/audio: helical track
O
Time code: helical track (sub-code area)
O
Cue signal: 1 track
O
Control (CTL) signal: 1 track
Tape speed
O
DVCPRO50: 67.640 mm/sec.
O
DVCPRO: 33.820 mm/sec.
Recording time
O
92 min. (using AJ-5P92LP, DVCPRO50)
O
33 min. (using AJ-P66MP, DVCPRO50)
O
184 min. (using AJ-5P92LP , DVCPRO)
O
66 min. (using AJ-P66MP, DVCPRO)
Tape used
1/4˝ thin magnetic layer metal tape
FF/REW time
Less than 5 minutes (using AJ-5P92LP)
[VIDEO]
$ Digital video
Sampling frequency
(DVCPRO50)
Y: 13.5 MHz, P
B
/P
R
: 6.75 MHz
(DVCPRO)
Y: 13.5 MHz, P
B
/P
R
: 3.375 MHz
Quantizing
8 bits
Video compression system
DCT + variable length code
Error correction
Reed-Solomon product code
$ Analog composite IN/OUT
Video band
Y: 30 Hz to 4.5 MHz (±1 dB)
Differential gain
Less than 6%
Differential phase
Less than 4.5 degrees
Y/C delay
Less than 20 ns
K factor
Less than 2%
$ Adjustments (video output signals)
Video gain
More than ±3 dB
Chroma gain
More than ±3 dB
Hue
More than ±25 degrees
Setup
±10 IRE
Horizontal (H) phase
More than ±1.5 µs
SC phase (COARSE)
360 degrees
SC phase (FINE)
90 degrees
For AJ-5P92LP cassette tapes recorded using
the DVCPRO (25 Mbps) mode, use a VTR
supporting DVCPRO (25 Mbps) 184 minute
tapes.
