12
Tapes
Types of tapes and their recording
times
M size cassettes
O
50 Mbps mode
Tapes with a recording/playback length of up to
33 minutes:
O
25 Mbps mode
Tapes with a recording/playback length of up to
66 minutes:
L size cassettes
O
50 Mbps mode
Tapes with a recording/playback length of up to
92 minutes:
O
25 Mbps mode
Tapes with a recording/playback length of up to
184 minutes:
AJ-P34LP, AJ-P66LP, AJ-P94LP, AJ-P126LP,
AJ-5P92LP
For AJ-5P92LP cassette tapes recorded using
the DVCPRO (25 Mbps) mode, use a VTR
supporting DVCPRO (25 Mbps) 184 minute
tapes.
AJ-P12MP, AJ-P24MP, AJ-P33MP, AJ-P46MP,
AJ-P66MP
CH1
AUDIO OUT 25
CH1
ST
CH2
AUDIO MON SELECT
CH 3 · 4 50M bps
CH2
REC
INPUT SELECT
ON
OFF
C
B
POWER EJECT
LOCAL
MENU
ANALOG SDI OFF
REC INHIBIT
ON
REMOTE
PB
PULL
FOR VAR
PLAY PAUSE/STILL REC TAPE
EE SET DATA j i MODE MENU UP DOWN PAGE
REW STOP FF
SEARCH
RESET
COUNTOR
50
M size
cassette
L size
cassette
DV tapes bearing either the “ ” or “ ” logo for
regular consumer applications cannot be used. Do
not insert them into the unit.
Align the cassette with the center of the insertion slot,
and push it in gently.
Once inserted, the cassette tape is loaded
automatically.
