Genicom 3840 and 3410 ANSI Emulation
115
Vertical Position
Line Feed ESC D
Causes the current line to be printed and then advances the paper one line at the current line spacing. If
“Auto CR” is set to “On” in the interface setup menu, a carriage return will also be performed.
Control Code: LF
Hexadecimal 0A
Escape Sequence:
ESC D
Hexadecimal: 1B 44
Index IND
Advances the paper to the next line. The current column is not changed, regardless of the status of auto CR
on LF.
Control Code: IND
Hexadecimal: 84
Next Line ESC E
Causes the current line to be printed, and then sets the current print position to the left margin and performs a
line feed. Equivalent to a carriage return (CR) line feed (LF) combination.
Control Code: NEL
Hexadecimal: 85
Escape Sequence:
ESC E
Hexadecimal: 1B 45
Vertical Position Absolute ESC [(p)d
Moves the current print position to p decipoints from the top of the form.
The following example advances the paper to 2 inches below top of form.
Example: ESC [1440d
Escape Sequence: ESC [ 1 4 4 0 d
Hexadecimal: 1B 5B 31 34 34 30 64
Vertical Position Relative ESC [(p)e
Advances paper p decipoints. This command enables printing below the bottom margin of the current form
and above the top margin of the following form. The example below advances the paper 4 ¼ inches.
Example: ESC [3060e
Escape Sequence: ESC [ 3 0 6 0 e
Hexadecimal: 1B 5B 33 30 36 30 65
