Printek PrintMaster 850 Series - Manual (Page 120)

Genicom 3840 and 3410 ANSI Emulation
114
Control Code: ESC [ 2 0 h
Hexadecimal: 1B 5B 32 30 68
Reset Auto CR ON LF ESC [(p)l
Resets mode set by ESC [20h.
Example: reset auto CR on LF
Control Code: ESC [ 2 0 l
Hexadecimal: 1B 5B 32 30 6C
Horizontal Position Backwards ESC [(p)j
Moves the horizontal position (p) decipoints left of the current position.
Actual distance between symbols separated by this command is the argument (p) minus the current horizontal
pitch (text of graphics). For example, if you print an uppercase E at 10 cpi, move backwards by (p), and
print another uppercase E, then the distance between leading edges of the two characters is (p) – 72
decipoints. If you print graphics at 72 dpi, move backwards by p, and print another graphics column, then
the distance between the two graphics columns is (p) – 10 decipoints.
This command enables printing left of the left margin. Any data located left of the left print reference is
discarded.
Example: ESC [1080j moves the horizontal position back by 1.5 inches.
Control Code: ESC [ 1 0 8 0 j
Hexadecimal: 1B 5B 31 30 38 30 6A
Horizontal Position Absolute ESC [(p)’
Causes the print position to move (in decipoints) a specified distance from the left print reference.
Example: ESC [1080’
Control Code: ESC [ 1 0 8 0 ‘
Hexadecimal: 1B 5B 31 30 38 30 60
Horizontal Position Relative ESC [(p)a
Advances the current print position by the distance specified. Parameter p is specified in decipoints (720
decipoints = 1 inch).
Example: ESC [1080a advances the print position 1.5 inches
Control Code: ESC [ 1 0 8 0 a
Hexadecimal: 1B 5B 31 30 38 30 61
