4
SAFETY RULES
Look for this symbol to point out
important safety precautions. It means
CAUTION!!! BECOME ALERT!!! YOUR
SAFETY IS INVOLVED.
CAUTION: In order to prevent
accidental starting when setting up,
transporting, adjusting or making repairs,
always disconnect spark plug wire and
place wire where it cannot contact spark
plug.
CAUTION: Do not coast down a hill
in neutral, you may lose control of the
tractor.
CAUTION: Tow only the attachments
that are recommended by and comply
with specifications of the manufacturer of
your tractor. Use common sense when
towing. Operate only at the lowest
possible speed when on a slope. Too
heavy of a load, while on a slope, is
dangerous. Tires can lose traction with
the ground and cause you to lose control
of your tractor.
WARNING: Engine exhaust, some of
its constituents, and certain vehicle
components contain or emit chemicals
known to the State of California to cause
cancer and birth defects or other repro-
ductive harm.
WARNING: Battery posts, terminals
and related accessories contain lead and
lead compounds, chemicals known to the
State of California to cause cancer and
birth defects or other reproductive harm.
Wash hands after handling.
• Use slow speed. Choose a low gear so
that you will not have to stop or shift
while on the slope.
• Avoid starting or stopping on a slope. If
tires lose traction, disengage the
blades and proceed slowly straight
down the slope.
• If machine stops while going uphill,
disengage blades, shift into reverse
and back down slowly.
• Do not turn on slopes unless neces-
sary, and then, turn slowly and gradu-
ally downhill, if possible.
45
TRACTOR -- MODEL NUMBER 271470
MOWER DECK
56 165723 Spacer, Retainer
67 149846 Knob
68 144200 Belt
69 76020312 Pin, Cotter 3/32 x 3/4
86 7631J Runner, LH
87 128772 Runner, RH
88 19111216 Washer 11/32 x 3/4 x 16 Ga
89 19131612 Washer 13/32 x 1 x 12 Ga
107 133502 Spacer, Retainer
108 133503 Stiffener, Idler Arm
109 74760640 Bolt, Hex Head 3/8-16 x2-1/2
110 142587 Upstop Deck Front 38"
113 17060512 Screw 5/16-18 x 3/4
122 131289 Rod, Brake, LH
123 169971 Rod, Brake, RH
146 165891 Bolt Carriage Idler
148 169022 Spring Return Idler
149 165898 Retainer Spring Yellow Zinc
150 19091216 Washer 9/32 x 3/4 x 16 Ga.
151 169670 Bracket Clutch
152 172758 Cable Clutch 38 In
153 169674 Washer Flat 3/8” Type B
154 169675 Spring Retainer
155 169671 Spring Retention Lever
156 169672 Spacer
157 169669 Rod Clutch
158 17720410 Screw Hex Thd Cut
1/4-20x5/8
- - 130794 Mandrel Assembly (Includes
Key Numbers 12-15, 17-19,
31 and 33)
- - 171665 Mower Deck, Complete
1 170280 Mower Housing Assembly
2 72140506 Bolt, Carriage 5/16-18 x 3/4
3 138017 Bracket Asm. Fram Sway Bar
4 169970 Bracket, Asm. Deck Sway
Bar
5 4939M Retainer, Spring
6 130832 Asm. Suspension Rear
8 850857 Bolt, Hex 3/8-24 x 1-1/4 Gr 8
9 10030600 Washer, Lock, Hlcl Sprg 3/8
10 140296 Washer, Hard Blade Mower
Vented
11 134148 Blade, Mower, Mulching 38"
13 137645 Shaft and Bearing Assembly
(Includes Key Number 15)
14 128774 Mandrel Housing, Vented
15 110485X Ball Bearing, Mandrel
16 140329 Stripper, Mower, Vented
19 132827 Bolt, Shoulder
21 73680500 Nut, Crownlock 5/16-18
23 137607 Bracket, Mower Deflector
24 105304X Cap, Sleeve
25 123713X Spring, Deflector
26 110452X Nut, Push
27 106736X428 Shield, Deflector
28 19111016 Washer 11/32 x 3/4 x 16 Ga
29 106735X Rod, Hinge
30 157722 Screw, Thdro Washer Hd
31 129963 Washer, Spacer
32 153532 Pulley, Mandrel
33 137266 Nut, Flangelock 9/16
36 131494 Pulley, Idler, Flat
40 73680600 Nut Crownlock 3/8-16
45 4497H Retainer, Spring
53 130840 Brake Assembly
54 133943 Washer Hardened
55 133840 Idler Arm Assembly
KEY PART
NO. NO.
DESCRIPTION
NOTE: All component dimensions given in U. S.
inches 1 inch = 25.4 mm
KEY PART
NO. NO.
DESCRIPTION
