Page 17

TRACTOR

Always observe safety rules when
performing any maintenance.
BRAKE OPERATION
If tractor requires more than six (6) feet
stopping distance at high speed in
highest gear, then brake must be ad-
justed. (See “TO ADJUST BRAKE” in the
Service and Adjustments section of this
manual).
TIRES
• Maintain proper air pressure in all tires

(See “PRODUCT SPECIFICATIONS”
section of this manual).

• Keep tires free of gasoline, oil, or insect

control chemicals which can harm
rubber.

• Avoid stumps, stones, deep ruts, sharp

objects and other hazards that may
cause tire damage.

NOTE: To seal tire punctures and prevent
flat tires due to slow leaks, tire sealant
may be purchased from your local parts
dealer. Tire sealant also prevents tire dry
rot and corrosion.
OPERATOR PRESENCE SYSTEM
Be sure operator presence and interlock
systems are working properly. If your
tractor does not function as described,
repair the problem immediately.
• The engine should not start unless the

clutch/brake pedal is fully depressed
and attachement clutch control is in the
disengaged position.

• When the engine is running, any

attempt by the operator to leave the
seat without first setting the parking
brake should shut off the engine.

• When the engine is running and the

attachment clutch is engaged, any
attempt by the operator to leave the
seat should shut off the engine.

• The attachment clutch should never

operate unless the operator is in the
seat.

BLADE CARE
For best results mower blades must be

kept sharp. Replace bent or damaged
blades.

BLADE REMOVAL
• Raise mower to highest position to

allow access to blades.

• Remove hex bolt, lock washer and flat

washer securing blade.

• Install new or resharpened blade with

trailing edge up towards deck as
shown.

IMPORTANT: To ensure proper assembly,
center hole in blade must align with star
on mandrel assembly.
• Reassemble hex bolt, lock washer and

flat washer in exact order as shown.

• Tighten bolt securely (27-35 Ft. Lbs.

torque).

IMPORTANT: Blade bolt is Grade 8 heat
treated.

TO SHARPEN BLADE
NOTE: We do not recommend sharpen-
ing blade - but if you do, be sure the
blade is balanced.
Care should be taken to keep the blade
balanced. An unbalanced blade will
cause excessive vibration and eventual
damage to mower and engine.
• The blade can be sharpened with a file

or on a grinding wheel. Do not attempt
to sharpen while on the mower.

• To check blade balance, you will need

a 5/8" diameter steel bolt, pin, or a cone
balancer. (When using a cone bal-
ancer, follow the instructions supplied
with balancer.)

NOTE: Do not use a nail for balancing
blade. The lobes of the center hole may
appear to be centered, but are not.
• Slide blade on to an unthreaded

portion of the steel bolt or pin and hold
the bolt or pin parallel with the ground.
If blade is balanced, it should remain in
a horizontal position. If either end of
the blade moves downward, sharpen
the heavy end until the blade is
balanced.

*A Grade 8 heat treated bolt can be identified by six
lines on the bolt head.

Hex Bolt
(Grade)*

Mandrel
Assembly

Trailing
Edge Up

Flat Washer

Lock Washer

Center
Hole

Blade

Star

5/8” Bolt or Pin

Center Hole

Blade

BATTERY
Your tractor has a battery charging system
which is sufficient for normal use. How-
ever, periodic charging of the battery with
an automotive charger will extend its life.

TRACTOR -- MODEL NUMBER 271740

CHASSIS AND ENCLOSURES

208

209

145

206

205

212
