Figure 6, Rx connector (bnc) – Patton electronic 2635 User Manual
Page 30
Hardware installation
30
Models 2603, 2621, and 2635 Getting Started Guide
3 • Initial Configuration
Figure 6. Rear view of the 2603/K showing location of Ethernet and WAN connectors
The interface cable has been installed, go to section
“Installing the AC power cord”
Crossover
10/100
Ethernet
WA
N
MDI-X
Crossover
10/100
Ethernet
WAN
Power
Power
MDI-X
RX connector
(BNC)
RX
TX
RX
TX
TX connector
(BNC)
WAN connector
(RJ-48C)
Ethernet connector
(RJ-45)
