The Initial Setup menu 13
93
En
Manual CH Setting Next Screen Proceed to the next screen if you need to adjust any of the settings
made by auto tuning. Select your country, then proceed to the manual
channel setting screen:
• Change channel presets using the
CH +/– buttons.
• To skip the displayed channel (because there is no station assigned
to that channel), change the
Skip setting to On .
• To manually fine tune the channel, change the AFT setting to Off
then adjust the Level setting.
VCR Plus+ CH Setting Next Screen Proceed to the next screen to assign channel numbers to the guide
channels as necessary. Look in your TV guide to see which channel
numbers should be assigned to which guide channels. Press
ENTER
when your done to leave this screen.
Video In/Out Settings
Input Colour System Next Screen Proceed to the next screen to set the input colour system for each
channel preset. Use the
CH +/– buttons to change the preset. On the
default Auto setting the recorder can generally correctly detect
whether the input signal is 3.58 NTSC or PAL-M, but in some cases you
may have to set it manually if the picture is displayed incorrectly.
If the
Input Line System setting is 625 System then the Input Colour
System is automatically set to PAL-N.
See also About the input colour system on page 98 for more information on this setting.
Component Video Out Interlace • Select if your monitor/TV is not compatible with progressive-scan
video.
Progressive Select if your monitor/TV is progressive-scan compatible. Check the
operating instructions that came with your monitor/TV if you’re not
sure.
NTSC on PAL TV On NTSC discs will play correctly on PAL-only TVs.
Off • Use if your TV is already NTSC-compatible.
Many recent PAL TVs are compatible with NTSC input and so this setting can be switched off. Check the operating instructions that came with
your TV. See also About NTSC on PAL TV on page 98 for related information.
Audio In Settings
External Audio Stereo • Select if the audio from the currently selected external input is stan-
dard stereo.
Dual Mono Select if each channel carries a separate soundtrack.
When the external audio is from the DV input, an audio subcode channel within the DV audio tells the recorder whether the audio is stereo or dual
mono. This has priority over the setting you make here.
Dual Mono Recording L • Select to record the left channel of an external dual mono source when
recording to DVD in Video mode,to HDD with HDD Recording Format
set to Video Mode On, or in
LPCM mode.
R As above, but for right channel recording.
When recording dual mono audio to DVD in VR mode (except in LPCM mode), or to HDD with HDD Recording Format set to Video Mode Off (except
in LPCM mode), both audio channels are recorded and you can switch to the one you want on playback.
Setting Options Explanation
