Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
1 VXA7511 CASSETTE COMPARTMENT 1
2 VXA7344 HOLDER ASS'Y 1
3 VXA6893 TOP PLATE 1
4 VXL2696 PRESSURE LEVER 2
5 VMB3063 PRESSURE LEVER SPRING 2
6 VXA6728 PROTECTOR SHAFT (2) L 1
7 VXA6729 PROTECTOR SHAFT (2) R 1
8 VMS6198 PROTECTOR SHAFT 1
9 VMD3951 PROTECTOR SHAFT (1) 1
10 VMB3135 SHAFT RELESE SPRING 1
11 VML3651 RELEASE LEVER (L) 1
12 VMB3140 LOCK RELEASE LEVER SPRING 1
13 VXA6885 SIDE PLATE (L) 1
14 VXL3050 RATCHET ARM 1
15 VXL3060 RATCHET LOCK LEVER 1
16 VXL3052 RATCHET LEVER 1
17 VMB2981 RATCHET SPRING 1
18 VMB3146 LOCK LEVER SPRING 1
19 VXA6886 SIDE PLATE (R) 1
20 VXP0891 DUMPER 1
21 VDP1880 MAIN ARM ROLLER 2
22 VMB3133 UP SPRING 2
23 VXA6853 PROTECTOR PLATE 1
24 VXA6888 BACK PLATE 1
25 VMD2793 SHAFT 2
26 VML3915 RATCHET TIMING LEVER 1
27 VMB2982 SPRING 1
28 VMB3134 PLATE RELEASE SPRING 1
29 VMS6211 PROTECTOR PLATE SHAFT 1
30 VML3652 RELEASE LEVER (R) 1
31 VXA6730 WATER PROOF ASS'Y 1
34 VMA0G36 SIDE RAIN FORCE L 1
35 VMA0M96 SHIELD (L) 1
36 VMD0997 HOLDER GUIDE 1
37 VMA0M97 RADIANT SHIELD R 1
38 VDG1456 DUMPER GEAR 1
39 VMB3164 LOCK RELEASE LEVER SPRING 1
40 VSC4874 CLIP FINGER 2
51 VMX0967 CUT WASHER 14
52 XWGV2D5G WASHER 2
53 VMX1079 CUT WASHER 2
54 XWGV2Y5G WASHER 7
55 XWGV2Z5G WASHER 2
56 XWGV2F5G WASHER 2
57 XYN2+J5FJ SCREW 2
58 XYN3+J6FJ SCREW 2
59 XUC2FP E-RING 2
60 XQN16+A6FJ SCREW 1
61 XQN2+A3FJ SCREW 2
62 VHD1323 SCREW 11
63 LMHD16064 SCREW 2
64 XWGV3Y8G WASHER 2
65 XWGV4Y8G WASHER 2
66 XYN2+C4FJ SCREW 2
CASSETTE COMPARTMENT ASSEMBLY
MPL-7
