TABLE OF CONTENTS
Section Page
1.0 Warranty Information .............................................................2
1.1 Radio and TV Interference
1.2 CE Notice
1.3 Service
2.0 General Information...............................................................4
2.1 Features
2.2 Description
3.0 PPP Operational Background................................................5
3.1 Applications
4.0 Installation ............................................................................7
4.1 Connect to 10BaseT Ethernet Port
4.1.1 Connect the 10BaseT Ethernet Port to a Hub
4.1.2 Connect the 10BaseT Ethernet Port to a PC (DTE)
4.2 Connect to the DTE Interface
4.3 Power Connection
4.3.1 AC Power Supply (100-240VAC)
4.3.2 DC Power
5.0 Configuration........................................................................11
5.1 LED Status Monitors
5.1.1 LAN side LEDs
5.1.2 LED Descriptions
5.1.3 Power and DCE/DTE Interface LEDs
Appendix A - 2121 Specifications ...............................................15
Appendix B - 2135C Specifications............................................16
Appendix C - Factory Replacement Parts ..................................17
Appendix D - 10BaseT Interface Pin Assignment ......................18
Appendix E - X.21 Terminal Interface Pin Assignment ...............15
Appendix E - V.35 Terminal Interface Pin Assignment ...............20
Appendix G - Power Supply Interface ........................................21
1
1.0 WARRANTY INFORMATION
Patton Electronics warrants all Model 2121/2135C components to
be free from defects, and will—at our option—repair or replace the
product should it fail within one year from the first date of shipment.
This warranty is limited to defects in workmanship or materials,
and does not cover customer damage, abuse or unauthorized modifi-
cation. If this product fails or does not perform as warranted, your sole
recourse shall be repair or replacement as described above. Under no
condition shall Patton Electronics be liable for any damages incurred
by the use of this product. These damages include, but are not limited
to, the following: lost profits, lost savings and incidental or consequen-
tial damages arising from the use of or inability to use this product.
Patton Electronics specifically disclaims all other warranties, expressed
or implied, and the installation or use of this product shall be deemed
an acceptance of these terms by the user.
1.1 RADIO AND TV INTERFERENCE
The Model 2121/2135C generates and uses radio frequency ener-
gy, and if not installed and used properly—that is, in strict accordance
with the manufacturer’s instructions—may cause interference to radio
and television reception. The Model 2121/2135C has been tested and
complies with the limits for a Class A computing device in accordance
with the specification in Subpart J of Part 15 of FCC rules, that are
designed to provide reasonable protection from such interference in a
commercial installation. However, this is no guarantee that interfer-
ence will not occur in a particular installation. If the Model 2121/2135C
does cause interference to radio or television reception, which can be
determined by disconnecting the unit, the user is encouraged to try to
correct the interference by one or more of the following measures:
moving the computing equipment away from the receiver, re-orienting
the receiving antenna and/or plugging the receiving equipment into a
different AC outlet (such that the computing equipment and receiver
are on different branches). In the event the user detects intermittent or
continuous product malfunction due to nearby high power transmitting
radio frequency equipment, the user is strongly advised to use only a
shielded twisted pair data cable that is bonded to metalized external
outer shield plugs at both ends. The use of a shielded cable satisfies
compliance with the Electromagnetic Compatibility (EMC) directive.
1.2 CE NOTICE
The CE symbol on your Patton Electronics equipment indicates
that it is in compliance with the Electromagnetic Compatibility (EMC)
directive and the Low Voltage Directive (LVD) of the Union European
(EU). A Certificate of Compliance is available by contacting Patton
Technical Support.
2
