18

APPENDIX D

10BaseT Interface Pin Assignment

(RJ-45 Female Connector)

(DTE Configuration)

Pin #

Signal

1 TD +

(data output from 2121/2135C)

2 TD -

(data output from 2121/2135C)

3 RD +

(data input to 2121/2135C)

4 no

connection

5 no

connection

6 RD -

(data input to 2121/2135C)

7 no

connection

8 no

connection

17

APPENDIX C

2121/2135C FACTORY

REPLACEMENT PARTS

Part #

Description

07M2121/2135C........2121/2135C User Manual
0805DCUI..................100-250 VAC Universal Power Supply
