MODEL SG6H FRYER
PREVENTATIVE MAINTENANCE
L20-332, rev. 1 (05/11) 19
1. Filter Pan
2. Filter Pickup Assembly
3. Filter Strainer Cap
4. Filter
Paper
5. Filter Screen
3.1.3. REPLACING THE FILTER MEDIA (IF EQUIPPED)
Refer to the following procedure to replace the filter media if the appliance is equipped with a filter
drawer.
1. Detach the pickup tube from the filter pickup
assembly by unscrewing it (counterclockwise),
at the knurled fitting, from the threaded fitting on
the filter screen.
2. Slide off the filter paper clip and remove used
filter paper from filter screen. Replace with new
filter paper, ensuring that the hole in the paper is
on the top, so that threaded fitting in filter screen
protrudes through it.
3. Fold filter paper to the underside of the filter
screen and replace filter paper clip.
4. Re-attach filter pickup tube to the filter screen by
screwing it (clockwise) into the threaded fitting in
filter screen.
5. Reinstall the filter pickup assembly into the filter
system by placing the newly covered screen
portion of the assembly into the filter pan and connecting the quick disconnect on the filter
pickup assembly into white donut fitting on the left-hand side of the appliance. Ensure that
it snaps tightly and securely into donut fitting.
3.1.4. APPLIANCE INSPECTION
 Check that the high temperature limit and temperature probe are in the correct position and
secured in place.
 Check that wires and cords are not frayed or loose in and out of the cabinet.
 Check around the appliance for loose parts or accessories that need to be secured or other
foreign items (ex: Aerosol cans) that should be removed from the area.
 Check for oil/shortening leaks around the in and out of the cabinet and around the
appliance.
WARNING
The power supply must be disconnected before cleaning and servicing this appliance!
WARNING
Wear protective gloves and clothing when cleaning and draining the appliance and
when disposing of water. The water is extremely hot and can cause severe injuries.
