Powerware 9170+ User Manual
Page 5

RACKMOUNT INSTALLATION
EATON Powerware
®
9170
+
Rail Kit (9− and 12−Slot Cabinets) Installation Guide
S
164201420 Rev C www.powerware.com
3
4.
Install six metal clip nuts (nine clip nuts for 12−slot cabinets) onto
each side flange along the front of the cabinet (see Figure 2).
NOTE DO NOT install metal clip nuts in the bottom cabinet section.
Tab Slots
Metal Clip Nuts
Tab Slots
Tab Slots
Metal Clip Nuts
Metal Clip Nuts
Figure 2. Metal Clip Nut and Tab Slot Locations
