DEH-2130R,2100R
+ ≠
+ ≠
Note: Depending on the kind of vehicle, the func- tion of 3* and 5* may be dif
ferent. If this is
the case, be sure to connect 2* to 5* and 4* to
5.
4*
5* 3*
1*
2*
1. This
product
2. Rear output
3. Antenna
jack
6. Connect leads of the same
color to each other
.
7. Cap (1*)
When not using this terminal, do not remove the cap.
8. Y
ellow
(3*)
Back-up (or accessory)
9. Y
ellow
(2*)
T
o
terminal always supplied
with power regardless of ignition switch position.
10. Red (5*)
Accessory (or back-up)
1
1
. Red (4*)
T
o
electric terminal con-
trolled by ignition switch (12 V
DC)
ON/OFF
.
19. Fuse holder
12. Black (ground)
T
o
vehicle (metal) body
.
13. ISO connector
Note: In some vehicles, the ISO connector may be divided into two. In this case, be sure to connect to both connectors.
18. Y
ellow/black
If you use a cellular telephone, connect it via the
Audio Mute lead on the cellular telephone.
If not, keep the
Audio Mute lead free of any
connections.
17. Fuse resistor
14. Speaker leads
White
: Front left
+
White/black
: Front left
≠
Gray
: Front right
+
Gray/black
: Front right
≠
Green
: Rear left
+
Green/black
: Rear left
≠
V
iolet
: Rear right
+
V
iolet/black
: Rear right
≠
22. Blue/white (6*)
23. Blue/white (7*)
T
o
Auto-antenna relay control terminal.
(Max. 300 mA
12
V
DC.)
24.
The pin position of the ISO connector will dif
fer
depends on the type of vehicle. Connect 6* and 7* when Pin 5 is an antenna control type. In another type of vehicle, never connect 6* and 7*.
26. Perform these connections when using
a dif
ferent amp (sold separately).
25. Rear speaker
25. Rear speaker
21. System remote control
20. Blue/white
T
o
system control terminal of the power amp.
(Max. 300 mA
12
V
DC.) 15. Connecting cords with
RCA
pin plugs (sold separately)
16. Power amp
(sold separately)
4. Fuse
