39
DEH-2130R,2100R
R
907
RS1/16S103J
R
908
RS1/16S681J
R
909
RS1/16S473J
R
914
RS1/16S562J
CAPACITORS
C
1
CCSQCH5R0C50
C
2
CCSRCH5R0C50
C
4
CCSRCJ3R0C50
C
6
CKSQYB105K10
C
8
CKSRYB222K50
C
10
CCSRCH220J50
C
11
CCSRCH150J50
C
12
CCSRCH8R0D50
C
14
CCSRCJ3R0C50
C
15
CKSRYB103K50
C
16
CKSRYB222K50
C
17
CKSRYB222K50
C
18
CCSRCJ3R0C50
C
19
CKSRYB103K50
C
20
CKSRYB103K50
C
21
CKSRYB103K50
C
24
CKSQYB334K16
C
31
CKSRYB222K50
C
32
CCSRCH470J50
C
35
CKSRYB103K50
C
51
CKSRYB103K50
C
52
CKSRYB473K16
C
53
CCSRCK2R0C50
C
54
CKSRYB103K50
C
55
CKSRYB104K16
C
56
CKSRYB104K16
C
58
CKSQYB224K16
C
59
CKSRYB223K25
C
60
CKSRYB104K16
C
101
CEALNP100M10
C
102
CCSRCH151J50
C
103
CKSRYB473K16
C
105
CKSRYB682K25
C
106
CEAL2R2M50
C
107
CKSRYB103K50
C
108
CKSQYB474K16
C
109
CKSQYB474K16
C
110
CKSRYB104K16
C
111
CKSRYB104K16
C
112
CKSRYB104K16
C
113
CKSRYB123K25
C
114
CEAL220M6R3
C
115
CKSRYB473K16
C
116
CEAL2R2M50
C
117
CKSRYB102K50
C
120
CKSRYB153K25
C
121
CKSRYB332K50
C
122
CKSRYB682K25
C
123
CKSRYB681K50
C
125
CKSRYB103K50
C
126
CKSRYB103K50
C
127
CEAL2R2M50
C
128
CKSRYB103K50
C
201
CCSRCH471J50
C
202
CCSRCH100D50
C
203
CKSRYB104K16
C
204
CKSRYB332K50
C
205
CKSRYB103K50
C
206
CKSRYB104K16
C
207
CKSRYB473K16
C
208
CCSRCH560J50
C
209
CEAL470M6R3
C
210
CKSRYB103K50
C
211
CKSRYB103K50
C
212
CCSRCH101J50
C
215
CKSRYB223K25
C
216
CKSQYB334K16
C
217
CKSRYB103K50
C
219
CKSQYB105K10
C
220
CKSRYB104K16
C
221
CKSRYB473K16
C
222
CKSQYB334K16
C
223
CKSQYB474K16
C
224
CKSRYB104K16
C
225
CKSRYB272K50
C
226
CKSRYB682K25
C
902
CCSRCH270J50
C
904
CKSRYB223K25
C
905
CKSRYB103K50
C
906
CCSRTH100D50
C
907
CCSRTH150J50
C
909
CCSRTH100D50
C
910
CKSRYB332K50
C
912
CKSQYB474K16
C
913
CKSRYB223K25
C
914
CKSRYB682K25
C
915
CKSQYB223K25
C
916
CKSQYB474K16
C
917
CKSYB475K10
C
918
CKSRYB223K25
C
919
CKSQYB225K10
C
920
CCSRCH270J50
C
921
CCSRCH270J50
C
922
CKSYB105K16
C
923
CKSRYB103K50
Unit Number : CWM6779(DEH-2130R)
: CWM6778(DEH-2100R)
Unit Name
: Keyboard Unit
MISCELLANEOUS
IC
1801
IC
PD6293A
D
1801
Diode
MA152WK
D
1802
Diode
MA152WA
X
1801
Ceramic Resonator 4.97MHz
CSS1422
IL
1801
Lamp 14V 40mA(DEH-2130R)
CEL1638
IL
1801
Lamp 14V 40mA(DEH-2100R)
CEL1547
IL
1802
Lamp 14V 40mA(DEH-2130R)
CEL1638
IL
1802
Lamp 14V 40mA(DEH-2100R)
CEL1547
IL
1803
Lamp 14V 40mA(DEH-2130R)
CEL1638
IL
1803
Lamp 14V 40mA(DEH-2100R)
CEL1547
IL
1804
Lamp 14V 40mA(DEH-2130R)
CEL1638
IL
1804
Lamp 14V 40mA(DEH-2100R)
CEL1547
LCD1801
LCD
CAW1559
RESISTORS
R
1801
RS1/8S222J
R
1802
RS1/8S222J
R
1803
RS1/10S471J
R
1804
RS1/10S471J
R
1805
RS1/10S471J
R
1806
RS1/10S471J
CAPACITORS
C
1801
CKSQYB103K25
=====Circuit Symbol and No.===Part Name
Part No.
---
------
------------------------------------------
-------------------------
=====Circuit Symbol and No.===Part Name
Part No.
---
------
------------------------------------------
-------------------------
C
