5
DEH-2130R,2100R
1 Screw BMZ26P120FMC
2 Screw BSZ26P060FMC
3 Screw BSZ30P060FMC
4 Screw BSZ30P120FMC
5 Cord Assy CDE6123
6 Cable CDE6160
7 Fuse(10A) CEK1136
8 CD Mechanism Module(S8.1) CXK5203
9 Cover CNC8367
10 Holder CNC8884
11 Spacer CNM4913
12 Insulator CNM6224
13 Insulator CNM6386
14 •••••
15 Tuner Amp Assy
CWM6764
16 Screw ASZ26P080FMC
17 Screw BPZ26P080FMC
18 Screw BSZ26P160FMC
19 FM/AM Tuner Unit CWE1500
20 Holder CNC7532
21 Pin Jack(CN301) CKB1041
22 Terminal(CN403) CKF1059
23 Connector(CN901) CKM1299
24 Connector(CN601) CKS3581
25 Connector(CN605) CKS3838
26 Antenna Jack(CN402) CKX1056
27 Holder CNC7533
28 Holder CNC8041
29 Holder CNC8043
30 Holder CNC8588
31 Insulator CNM5967
32 Heat Sink CNR1506
33 Holder Unit CXB2687
34 Case Unit CXB4033
35 Button CAC4836
36 Spring CBH1835
37 Spring CBH2208
38 Spring CBH2367
39 Bracket CNC6791
40 Holder CNC8042
41 Cover CNM6276
42 Panel See Contrast table(2)
43 Arm CNV4692
44 Arm CNV4728
45 Arm CNV5576
46 Screw IMS20P030FZK
47 Detach Grille Assy See Contrast table(2)
48 Screw BPZ20P100FZK
49 Button(Detach) See Contrast table(2)
50 Button(+, -) See Contrast table(2)
51 Chassis Unit See Contrast table(2)
52 Screw ISS26P055FUC
53 IC(IC302) TDA7384
54 Transistor(Q904, 981) 2SD2396
55 Button(Source) CAC6494
56 Button(1-6) CAC6275
57 Button(B, A, Cross) See Contrast table(2)
58 Button(Eject) CAC6277
59 Spring CBH2210
60 Cover See Contrast table(2)
61 Keyboard Unit See Contrast table(2)
62 LCD(LCD1801) CAW1559
63 Connector(CN1801) CKS3580
64 Holder CNC8517
65 Rubber CNV5954
66 Lighting Conductor CNV5965
67 Rubber CNV5966
68 Grille Unit See Contrast table(2)
69 Cap CNS1472
70 Resistor RS1/2PMF102J
(1) EXTERIOR SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
Part No.
Mark No. Symbol and Description DEH-2130R/X1M/EW DEH-2100R/X1M/EW
42 Panel CNS5340 CNS5188
47 Detach Grille Assy CXB4595 CXB4592
49 Button(Detach) CAC5929 CAC5789
50 Button(+, -) CAC6458 CAC6273
51 Chassis Unit CXB4624 CXB4623
57 Button(B, A, Cross) CAC6459 CAC6276
60 Cover CNS5773 CNS5772
61 Keyboard Unit CWM6779 CWM6778
68 Grille Unit CXB4612 CXB4611
(2) CONTRAST TABLE
DEH-2130R/X1M/EW and DEH-2100R/X1M/EW are constructed the same except for the following:
