1 Names and Locations
16
9. Navigator keys: Used to select on-screen items or aim the camera in a
different direction.
10.
[ENTER]: Depending on the current screen, selects the highlighted setting or
item, saves the current setting, or aims the camera at the home position (see
page 59).
11. [RETURN] Returns to the previous or menu.
12. [ALERT]: Turns the buzzer on and off. The buzzer can be used to alert you to
camera sensor detection.
13.
[REC]: Press while monitoring a camera to record a movie.
14.
[SNAPSHOT]: Press while monitoring a camera to take a picture.
Insert the batteries
Active range
The remote control can be used up to 7 m (23 ft.) away and within a 30 degree
angle from the remote control sensor.
While pulling the cover
toward you, lift it up. Insert the batteries,
orienting the + and -
poles as indicated. Align the cover and
press down until it
snaps into place.
30˚ 30˚
Signal
transmitter
Remote control sensor
