1 Names and Locations
12
1Table of Contents
1 Names and Locations
1.1 Main Unit
Front Panel
1. SD Memory Card port (see page 72)
2.
Timer/Busy indicator (see page 13)
3.
Power indicator (see page 13)
4. Alert indicator (see page 13)
5. Sensor indicator (see page 13)
6. LAN indicators (see page 13)
7. Wireless indicator (see page 13)
8. Remote control sensor (see page 16
)
Rear Panel
1. DC IN jack (see page 23 or page 32)
2. Video output port (see page 23 or page 32)
3. LAN ports (see page 26 or page 32)
4.
Mode switch (see page 23 or page 32)
5.
FACTORY DEFAULT RESET button (page 131)
6. Antenna
(1)
(8) (2)
(3) (4) (5) (7)
(6)
(1)
(2) (3) (6)
(5) (4)
