34
REPAIR PARTS
SNOW THROWER - MODEL 961980022 (96198002200)
CHASSIS / ENGINE / PULLEYS
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
1
2
3
4
4
3
01.00.008-A
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
- - - - - - - ENGINE, TEC, MODEL
OH318SA-221835B
1 409346X428 FRAME
2 417014X428 ENGINE MOUNT PLATE
3 150406 BOLT 3/8−16
4 150078 SCREW 5/16−18 X .750
1
01.14.008-A
1 35062 SAFETY IGNITION KEY
