3 Camera connector [CAMERA I/F]
Connected to the camera (AK-HC900P) with the attached multi-cable.
4 Swivel stand control signal output connector [PAN/TILT CONTROL OUT]
Connected to the swivel stand.
5 Control data input connector [DATA IN]
Used to input the data multiplexed by the camera controller (AK-HRP900P).
5
CAMERA
CN
DATA IN BEAKER
DC 12V
IN
PAN/TILT
CONTROL OUT
3 4 5 7 6
_ Rear panel
1 7 2 3 4 5 6
8 9 10 11 12 13 14 15
1 7 2 3 4 5 6
8 9 10 11 12 13 14 15
1 7 2 3 4 5 6
8 9 10 11 12 13 14 15
Controls and their Functions
Signal
NC
NC
NC
NC
DC 12V
Frame GND
TXD (H)
Pin No
8
9
10
11
12
13
14
15
Signal
NC
NC
NC
NC
DC GND
TXD (C)
RXD (H)
RXD (C)
Pin No
1
2
3
4
5
6
7
TXD: Data from camera to remote controller.
RXD: Data from remote controller to camera.
Pin No
1
2
3
4
5
6
7
Signal
NC
NC
NC
NC
NC
Frame GND
TXD (H)
Pin No
8
9
10
11
12
13
14
15
Signal
NC
NC
NC
NC
NC
TXD (C)
RXD (H)
RXD (C)
