Panasonic AK-HTF900P User Manual
Page 3
3
Contents
For Your Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Precautions for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Controls and their Functions
_
Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
_
Rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
How To Connect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Appearance and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Outline
≥
This unit is able to separate multiple data (camera control data and swivel stand control
data) transmitted from the camera controller (AK-HRP900P), and to output the control
information to the multi-purpose camera (AK-HC900P) and the swivel stand (AW-
PH300A, etc.).
≥
The distance between this unit and the camera is 33 ft (10m) max.
Precautions for Use
≥
We recommend that the AC adapter AW-PS505P is used for power supply.
≥
Handle the unit with care.
If dropped or given a strong shock, it may cause a trouble or accident.
≥
Use the unit in a temperature range of 32
o
F to 104
o
F (0
o
C to + 40
o
C).
If used at a temperature below 32
o
F or higher than 104
o
F, it may cause bad influences to
the component parts.
≥
Turn off the power before connecting or disconnecting the cable.
When connecting or disconnecting the cable, be sure to turn off the power switch of the
unit beforehand.
≥
Avoid using the unit outdoors.
≥
Install the unit 3.3 ft (1 m) away from the monitor.
≥
Maintenance
Pull out the power cord plug and clean the unit with dry cloth. If it is hard to clean,
moisten the cloth with a diluted neutral detergent solution and squeeze it well and lightly
wipe the unit.
≥
Do not use volatile solvents such as benzene or thinner.
≥
When using a chemical mop, carefully read the instructions.
Precautions
