Getting Started 9

Installation & Operating Instructions

Owner’s Reference

PowerPack 1500 MKII

AC Mode
The UPS delivers power to the loads derived from the utility and maintains
proper battery charge. It also regulates the output voltage to within a narrow
range and serves to isolate the load from surges and electrical noise brought by
the utility wiring.

On Battery Mode
The UPS operates on battery when the line voltage or frequency has fallen out-
side the limits. Users are alerted to this mode of operation by visual indicators.
The UPS provides power to the load from the battery and through its inverter
and the output voltage and frequency of the UPS are regulated within a narrow
band.

Function

Panel Indicator

Switch on

Press and hold the main on switch on the front panel for more than 3
seconds until the “AC normal” green LED lights up. The UPS will perform a
self-test every time it is switched on.

Test

Use the test function to check both the operation of the UPS and the condition of
the battery.

In AC operating mode, the level indicator will show the actual load connected to
this UPS normally. Press and hold the “I” switch on the front panel for more than
3 seconds. The level indicator will show the battery voltage for 10 seconds.

During this 10 seconds, if you press and hold the “I” switch for more than 3 sec-
onds again, this UPS will enter into testing mode. The battery will provide power
to the load during this period. Testing mode will check the status of the battery
and operation of the UPS , last for 10 seconds and transfer back to normal status
automatically.

Testing mode can not be performed if the load connected is greater than 100% or
the charging voltage is lower than 26Vdc.

Alarm
Silence

In battery backup mode, the level indicator will show the battery voltage level.
Press and hold the “I” switch on the front panel for more than 3 seconds. The
level indicator will show the load level for 10 seconds.

2.4 Operation and

Functionality Test
