Installation & Operating Instructions
Owner’s Reference
PowerPack 1500 MKII
Press and hold the main on switch “I” for more than 3 seconds to turn on the
right most LED. This indicates that the UPS is configured to work at 50Hz output
frequency.
Press and hold the main switch “I” again for more than 3 seconds to configure
the UPS to operate in the 60Hz mode.
Note: the battery backup mode output frequency will always follow the frequency of AC mains,
even if the internal presetting is different.
2.6.4.1 Output
‘Frequency Setting
2.6.4 Setting of
Parameters
50Hz
LED on continuously
LED flashing
60Hz
