The Video/Audio Adjust menu 12
92
En
5 When you have all the settings as you want
them, press HOME MENU to exit.
You can now use the preset for any other input or the
built-in TV tuner.
Tip
• To see more of the picture as you adjust different
settings, press ENTER after selecting the setting you
want to adjust.
Note
• DVR-520H only: When the DV input is selected, only
VNR and Detail settings can be adjusted.
• When White AGC is On, the White Level setting
can’t be adjusted.
Setting the picture quality for disc
playback
This setting determines how the picture will look when
playing discs.
Choosing a preset
1 With a disc playing (or paused), press HOME
MENU and select ‘Video/Audio Adjust’.
2 Select ‘Video Adjust’
3 Use the / (cursor left/right) buttons to
change the setting.
There are six presets available:
• TV(CRT) – suitable for standard cathode-ray tube TVs
• PDP – suitable for plasma display screens
• Professional – suitable for professional monitors
• Memory1 – user preset 1
• Memory2 – user preset 2
• Memory3 – user preset 3
You can press DISPLAY to see the individual settings for
the current preset ( TV(CRT), PDP or Professional).
4 Press ENTER to select the preset.
Creating your own set
There are three user presets in which you can save your
own set of picture quality settings for disc playback.
1 Follow Choosing a preset above and select one of
the user presets (Memory 1, 2 or 3).
2 Move the cursor down and select ‘Detailed
Settings’.
3 Select the picture quality setting you want to
adjust.
You can adjust the following settings:
• Pure Cinema – When watching DVD movies, Pure
Cinema optimizes the picture quality. If the picture
appears unnatural on the default
Auto setting,
change to On or Off as desired. (Note that this
setting can only be adjusted when the video output is
set to progressive.)
See also PureCinema in the Glossary on page 117.
• YNR – Adjusts the amount of noise reduction (NR)
applied to the Y (brightness) component (has no
effect when the video output is set to progressive).
• CNR – Adjusts the amount of noise reduction (NR)
applied to the C (color) component (has no effect
when the video output is set to progressive).
• QNR – Adjusts the amount of noise reduction (NR)
applied to the block noise.
• Detail – Adjusts how sharp edges appear.
• White Level – Adjusts the intensity of white.
• Black Level – Adjusts the intensity of black.
• Black Setup – Corrects the standard reference black
level.
• Hue – Adjusts overall balance between red and
green.
• Chroma Level – Adjusts how rich the colors appear.
TV(CRT)
Detailed Settings
Memory1
Detailed Settings
Memory1
Off Max
Off Max
Off Max
YNR
CNR
QNR
Off Max Detail
Min Max
Min Max
White Level
Black Level
Pure Cinema Auto
