Transmission Format: Sync or Async
Transmission Line: Full duplex over one or two
unconditioned twisted pairs (2 or 4 wires)
Line Encoding: 2B1Q with Integrated Echo
Cancellation.
Clocking: Internal, external or receive loopback
Distance: Up to 11.4 m/18.2 km (see table below)
Data Rates: 32, 56, 64, 128, synchronous (switch
selectable); 0 - 38.4 kbps, asynchronous
Carrier Control: “Constantly on” or “Contr. by RTS”
RTS/CTS Delay: no delay, short delay (4-8 ms), or
long delay (33-58 ms)
Diagnostics: local analog loopback, remote digital
loopback, V.52 compliant bit error rate pattern
(511/511E pattern) generator and detector with error
injection mode
LED Status Indicators: Dual red/green LEDs for
TD, RD, CTS and DC; green for DTR; red for ER,
TM and NS
Isolation & Protection: 1500V RMS (gas tube
surge protection optional)
DTE Interface: Depends upon interface module
Twisted Pair Interface: RJ-45 jack
Power: 120/230 VAC (switch selectable), 50/60 Hz;
100 - 240 VAC, 50/60 Hz (universal input option); 48
VDC (option). 5 watts.
Compliance: CE Marked per EMC Directive
89/336/EEC and Low Voltage Directive 73/23/EEC.
UL and cUL Safety Approvals.
Dimensions: 7.3” x 6.6” x 1.62” (185mm x 168mm
x 41mm)
Weight: 2.02 lbs.
7622 Rickenbacker Dr., Gaithersburg, MD 20879
Phone: (301) 975-1000 • Fax: (301) 869-9293 • E-mail: [email protected] • WWW: http://www.patton.com
Factory Part Numbers:
1 0 9 2 A /
I M
/
P S
/
Z
Interface Modules:
IM
= A = V24, DB25F
B = RS422/RS530, DB25F
C = V35, M34F
D = X21, DB15F
F = G703, RJ45
G = V.24, DB-25F (Async 57.6/115.2 kbps)
I = Ethernet WAN Bridge, RJ-45F
J = Data + Voice Combination (modular ports)
Power Supplies:
PS
= 120 = Switchable 120/230 Configured 120V
230 = Switchable 120/230 Configured 230V
UI = Universal Input Supply 100-240VAC
48 = 48 VDC
Power Cord Sets:
K
=American,
A
=European CEE 7,
D
=United Kingdom,
C
=Australia,
E
=Denmark,
F
=France/Belgium,
G
=India,
H
=Israel,
J
=Japan,
L
=Switzerland. (Others Available)
Power Cord
Power Supply
Interface Module
Base Unit
Examples:
1092A/A/120/A (V.24
DB-25F interface module, 120 VAC power supply, US power cord)
1092A/E/230/D (G.703
RJ-48S interface module, 230 VAC power supply, UK power cord)
S
PECIFICATIONS
S
PECIFICATIONS
Data Rate
(kbps)
128
11.4
(18.2)
7.6
(12.1)
5.3
(8.5)
3.6
(5.7)
64
11.4
(18.2)
7.6
(12.1)
5.3
(8.5)
3.6
(5.7)
56
11.4
(18.2)
7.6
(12.1)
5.3
(8.5)
3.6
(5.7)
32
11.4
(18.2)
7.6
(12.1)
5.3
(8.5)
3.6
(5.7)
0 - 38.4
11.4
(18.2)
7.6
(12.1)
5.3
(8.5)
3.6
(5.7)
Model 1092A 4-Wire Distances - Miles (Km)
Wire Gauge (AWG/mm)
19 (.7mm) 22 (.6mm) 24 (.5mm) 26 (.4mm)
O
RDERING
I
NFO
O
RDERING
I
NFO
Model 1092A
KiloModem™
, 2/4-wire,
sync/async baseband modem
Data Rate
(kbps)
128
10.8
(17.3)
7.2
(11.5)
5.0
(8.0)
3.4
(5.5)
64
10.8
(17.3)
7.2
(11.5)
5.0
(8.0)
3.4
(5.5)
56
10.8
(17.3)
7.2
(11.5)
5.0
(8.0)
3.4
(5.5)
32
10.8
(17.3)
7.2
(11.5)
5.0
(8.0)
3.4
(5.5)
0 - 38.4
10.8
(17.3)
7.2
(11.5)
5.0
(8.0)
3.4
(5.5)
Model 1092A 2-Wire Distances - Miles (Km)
Wire Gauge (AWG/mm)
19 (.7mm) 22 (.6mm) 24 (.5mm) 26 (.4mm)
