KiloModem
KiloModem
™
™
2-W
2-W
ir
ir
e/4-W
e/4-W
ir
ir
e Baseband Modem
e Baseband Modem
♦
♦
♦
♦
Synchronous data rates of 32, 56, 64
and 128 kbps in all clock modes
(Asynchronous data rates to 38.4 kbps)
♦
♦
♦
♦
Full duplex operation over one or two
twisted pairs (2 or 4 wires)
♦
♦
♦
♦
4-Wire distances up to 18 km (all data
rates) on 19 AWG twisted pair
♦
♦
♦
♦
Replaceable interface modules: G.703,
V.35, X.21, RS-422/530, V.24 (RS-232),
Ethernet WAN bridge & data + voice
♦
♦
♦
♦
2B1Q Modulation
♦
♦
♦
♦
In-Band and Out-of-Band remote
management capabilities
The
Patton Model 1092A
KiloModem™
supports point-to-point, synchronous or
asynchronous communication over one
or two twisted pairs (2 or 4 wires).
Offering switch selectable synchronous
data rates of 32, 56, 64 and 128 kbps,
the
KiloModem™
also supports asyn-
chronous speeds up to 38.4 kbps. The
Kilo-Modem™
is an excellent choice for
connecting two bridge/routers, or for simi-
lar networking applications at distances
up to 11.4 miles/18.2 km (4 wires).
Using the 2B1Q modulation scheme, the
KiloModem™
is able to send remote
management information on the “D”
channel. This means that a terminal con-
nected to the
KiloModem’s
RS-232 con-
trol port can be used to send in-band
Continued...
