User Settings
Mute/Attenuator
You can select how much to lower the
volume when [MUTE] is pressed.
Default: MUTE
Excluding AUX-IN from
Source Selection
Default: ON
Security Function
Default: ON
Press [MENU]/
[SEL] (MENU) to select
“FUNCTION” on the
menu display.
Press [P. SET
"] or
[P. SET
#]/["] or [#]
to select
MUTE KEY
Press [P. SET
"] or
[P. SET
#]/["] or [#]
to select
AUX-IN
Press [P. SET
"] or
[P. SET
#]/["] or [#]
to select
S-LED
Press [BAND] (SET) to switch between MUTE (mute) or ATT (attenuator) in turn.
MUTE
ATT
: No sound.
: Decrease the volume to 1/10.
Press [BAND] (SET) to activate the function or inactivate it in turn.
ON
OFF
: External input (AUX-IN) is selectable as a source.
: External input (AUX-IN) is not selectable as a source.
With AUX-IN set to OFF, AUX-IN will not be selected when [SOURCE] is pressed.
(
➡
page 12)
Press [BAND] (SET) to activate the function or inactivate it in turn.
ON
OFF
: Security function is active.
: Security function is non-active.
Security Function
When the key in the ignition is turned OFF.
≥
Security message will be active.
≥
The panel removable alarm will be active.
When the removable face plate is removed.
≥
The security indicator blinks. (
➡
page 33)
Notes:
≥
Operations except setting should be performed after
returning to the mode display.
≥
The display returns to the previous one with no op-
eration for 15 seconds after changing to the menu
display.
≥
Press [DISP] to return to the regular mode.
SET/AUTO•P
VOL
MENU
TUNE
SOURCE
D
•
M
CQ-DF701W
CD RECEIVER WIITH FULL DOT MATRIX DISPLAY
DIM
OPEN
TRACK
DISC
P
•
SET
BAND
REMOTE
MUTE
DISP
CH•C
!@
MOSFET
50W
X
4
S•HDB
HDB
;
/
1
PWR
[BAND] (SET)
[P.SET
"] [P.SET #]
(MENU SELECT)
[MENU]
[DISP]
[BAND] (SET)
[
"] [#]
(MENU
SELECT)
[SEL] (MENU)
[DISP]
SEL
Car Audio
SOURCE
POWER
VOL
MENU
DISP
MUTE
2
4
6
RAND
REP
1
3
5
SCAN
BAND
Function menu display
Security message display
1
Menu
2
Submenu
3
Setting
Regular mode
display
AUDIO
FUNCTION
