Related Patton-Inalp Products
The SmartNode product line also includes compact ISDN BRI router-gateways (SmartNode 1000
Series) and modular gateway routers for up to 4 E1 PRI (SmartNode 2000 Series).
The SmartNode products can be combined with Patton broadband transmission products such as
Ethernet Extenders, DSL Modems, Fibre Ethernet Extenders or Micro-Bridges to build integrated
voice data Intranets and carrier access solutions.
Patton Global Solutions also offers turn-key network deployments for enterprises and service
providers including 3rd party Softswitch installations providing pre and postpaid VoIP-Billing, Calling-
Card and Call-Shop operations.
What are the Key Features and Benefits of the SmartNode 4000 Series?
For a detailed feature listing refer to the current SmartNode/SmartWare Feature Matrix.
Key Features Benefit
General Compact low cost IP Router with dual 10/100 Ethernet and
integrated H.323, SIP (later MGCP) VoIP Gateway and 2 to 8
FXS and 2 or 4 FXO telephony interfaces.
Data Connectivity Two auto sensing full duplex 10/100 BaseT Ethernet (RJ-45)
ports with built in auto MDI-X switch
IP Connectivity DHCP server and client, Firewall, Access Control Lists (ACL),
PPPoE client
Voice Connectivity 2, 4, 6 or 8 FXS ports (2-wire, RJ-11/12) connect to any
standard handset or PBX trunk port. The FXS ports provide
CLIP, hook-flash and configurable tones.
2 or 4 FXO (2-wire, RJ-11/12) connect to analog lines
provided by public network operators or internal analog
extensions of PBX systems.
Call Routing The Session Router solves practically any call routing and
number mapping requirement including fallbacks. This is
critical for seamless integration into existing numbering plans
and networks.
With SmartWare 3.10 and later this functionality has been
enhanced even further to include routing rules and mapping
functions based on regular expressions.
VoIP Media Gateway
SIP and H.323
Standard Voice over IP Signaling with SIP and H.323v4,
Secure Gateway authentication with H.235
Standard voice compression CODECs G.711 (64k a-law, u-
law), G.723.1 (6.3k), G.729a/b (8k)* with configurable packet
length.
Echo cancellation, Silence suppression, comfort noise, DTMF
detection and relay (in-band and out-of-band), FAX Modem
Support: T.38 Fax-Relay Fax Gr 3 (14.4kb/s), Modem-Bypass
(G.711)
IPSec VPNs IPSec encapsulation and tunneling mode VPNs with pre-shared
keys and 3DES/AES encryption up to 256bit keys.
