June
DBS Release Notes
CPC-EX, Version 1 .O (Preliminary)
Hardware Requirements
l
A printer or external call accounting system is required to receive SMDR data.
Considerations
l
Unlike other CPC circuit cards, the CPC-EX supports two serial ports. Serial Port
1 is labeled CN4 and is located on the backplane. Serial Port 2 is labeled and
is located on the front of the CPC-EX card. Serial Port 2 requires a special
interface cable.
. Be sure to select the correct port to output SMDR data. From the Attendant’s
phone:
dial to set Serial Port 1 (the backplane port) to output Bus
Monitor/Maintenance and Serial Port 2 to no output.
dial to set Serial Port 1 to output SMDR and Serial Port 2 to output
Bus Monitor/Maintenance data.
to set Serial Port 1 to output SMDR data and Serial Port 2 to
no output.
Modifications to SMDR
l
