19

Hum and Noise:

Output

Residual Noise

S/N Ratio

Test Conditions

Ref: 0 dBu

Master L/R

-105 dBu

109 dB

All Faders Down

Mono

-90 dBu

94 dB

Master Fader Nominal,
Channel Faders Down,
All Channels Assigned

Submaster

-98 dBu

102 dB

All Faders Down

-88 dBu

92 dB

Submaster Fader
Nominal, Channel
Faders Down,
All Channels Assigned

(Hum and Noise Measurements: 22 Hz to 22 KHz BW)

Equivalent Input Noise (EIN):

-128 dBu (Input terminated with 150 Ohms)

Crosstalk:

>90 dB Adjacent Input Channels (20 Hz - 20 kHz)
>70 dB Left to Right Outputs (20 Hz - 20 kHz)

Common Mode Rejection Ratio (Mic Input):

50 dB min (20 Hz - 20 kHz)
70 dB typ @ 1 kHz

Meters:

L/R Master and all Submasters = 12 segment, peak reading
(0 dB= +4 dBu)

Signal / Overload Indicators:

Red LED lights 2 dB below clipping

Lamp Power:

12 VDC @ 350mA per connector, or 12VDC @ 700mA total maximum load

Power Requirements:

DOM: 100 VAC –240 VAC 50/60 Hz

70 Watts Nominal, 24 chan
80 Watts Nominal, 32 chan

RQ

4324

Height:

8.9" (226 mm)

Width:

36.6" (930 mm)

Depth:

19.5" (495 mm)

Weight:

36 lbs. (16.4 kg)

RQ

4332

Height:

8.9" (226 mm)

Width:

44.6" (1132 mm)

Depth:

19.5" (495 mm)

Weight:

48 lbs. (21.8 kg)

Dimensions:
