18
* 0 dBu = 0.775 V (RMS)
Output Specifications:
Function Minimum Output Levels, Bal./ Connector
Load Z Nominal Max. Unbal.
(Ohms)
Main L/R 600 +4 dBu +22 dBu Unbal. 1/4" Phono (Unbal);
Bal. XLR: Pin 1 Ground
Pin 2 (+)
Pin 3 (-) (Bal.)
Mono 600 +4 dBu +22 dBu Unbal. 1/4" Phono (Unbal.);
Bal. XLR: Pin 1 Ground
Pin 2 (+)
Pin 3 (-)
Sub Master 600 +4 dBu +22 dBu Unbal. 1/4" Phono
Aux Send 600 +4 dBu +22 dBu Unbal. 1/4" Phono (Unbal.);
XLR Pin 1 Ground
Pin 2 (+)
Pin 3 (-)
Channel 600 +4 dBu +22 dBu Unbal. 1/4" TRS: Tip Send,
Insert Send Ring Return,
Sleeve Ground
Headphone 8 +4 dBu +22 dBu Unbal. 1/4" TRS: Tip Left
(no load) Ring Right
Sleeve Ground
Gain:
Mic Input Gain Adj Range: 10 dB to 58 dB
Mic Input to Sub Output 78 dB (Max Gain)
Mic lnput Longest Path 88 dB (Max Gain)
Line Input Gain Adj Range: -10 dB to 38 dB
Line Input to Sub Output 58 dB (Max Gain)
Line Input Longest Path 68 dB (Max Gain)
Stereo Line Input Gain Adj Range -60 dB to 10 dB
Stereo Line Input to Sub Output 30 dB (Max Gain)
Stereo Line Input Longest Path 40 dB (Max Gain)
Aux Return to Sub Output 28 dB (Max Gain)
Aux Return Longest Path 38 dB (Max Gain)
Frequency Response:
Mic Input to L-R Output 20 Hz to 50 kHz +0 dB / -1 dB
Stereo Input to L-R Output 20 Hz to 30 kHz +0 dB / -1 dB
Total Harmonic Distortion (THD):
< 0.007% 20 Hz to 20 kHz Mic to L-R output at Nominal Level (20 Hz - 80 kHz BW)
