AV & COMPONENT / RGB connection
Connections
VIDEO P R /C R /R P B /C B /B Y/G AUDIO R L
COMPONENT/RGB IN
DIO L
A
DVD
Computer RGB Camcorder
or
Notes:
• Change the “COMPONENT/RGB-IN SELECT” setting in the “SET UP” menu to “COMPONENT”. (see page 38)
• Additional equipment, cables and adapter plugs shown are not supplied with this set.
Notes:
• Change the “COMPONENT/RGB-IN SELECT” setting in the “SET UP” menu to “RGB”. (see page 38)
• Additional equipment, cables and adapter plugs shown are not supplied with this set.
S VIDEO VCR
CAMCORDER
VCR
RCA-BNC
adapter
plug
Example of input signal source
Example of input signal source
Digital TV-SET-TOP-BOX
(DTV-STB)
RGB signal (R, G, B)
