CAM_ Gain
81 01 04 0C 00 FF
81 01 04 0C 02 FF
Gain Setting
81 01 04 0C 03 FF
81 01 04 4C 00 00 0p 0q FF pq: Gain Position
CAM_Bright
81 01 04 0D 00 FF
Bright Setting
81 01 04 0D 02 FF
81 01 04 0D 03 FF
81 01 04 4D 00 00 0p 0q FF pq: Bright Position
Command Set
Command
Command Packet
Comments
CAM_ExpComp
On
81 01 04 3E 02 FF
Off
81 01 04 3E 03 FF
pq: Aperture Gain
Reset
Down
Direct
Up
On
On
Off
Off
Position
Reset
Up
81 01 04 0E 00 FF
Exposure
Compensation
Amount Setting
81 01 04 0E 02 FF
81 01 04 0E 03 FF
81 01 04 4E 00 00 0p 0q FF
pq: ExpComp Position
CAM_ BackLight
81 01 04 33 02 FF
81 01 04 33 03 FF
Back Light
Compensation On/Off
81 01 04 59 02 FF
81 01 04 59 03 FF
81 01 04 29 0p 0q 0r 0s FF
pq: X (-toF)
rs: Y (0 to F)
81 01 04 02 00FF
81 01 04 02 02 FF
Exposure
Compensation
ON/OFF
CAM_SpotAE
CAM_Aperture
Down
Direct
81 01 04 02 03 FF
Aperture Control
81 01 04 42 00 00 0p 0q FF
CAM_LR_Reverse
On
81 01 04 61 02 FF
Off
81 01 04 61 03 FF
CAM_Freeze
Off
Neg. Art
B&W
Off
On
Off
81 01 04 62 03 FF
81 01 04 63 00 FF
81 01 04 63 02 FF
81 01 04 63 04 FF
CAM_ PictureFlip
81 01 04 66 02 FF
81 01 04 66 03 FF
Picture Flip On/Off
Mirror Image On/Off
On
81 01 04 62 02 FF
Still Image On/Off
CAM_PictureEffect
Picture Effect Setting
Infared Mode On/Off
On
Off
Off
81 01 04 01 02 FF
81 01 04 01 03 FF
81 01 04 51 03 FF
CAM_ICR
CAM_ Auto ICR
On
81 01 04 51 02 FF
Auto Infared Mode
On/Off
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
CAM_ZoomFocus
Direct
81 01 04 47 0p 0q 0r 0s
0t 0u 0v 0w FF
81 01 04 19 01 FF
Comp Scan
81 01 04 19 02 FF
Auto
81 01 04 35 00 FF
Correction of CCD
pixel blemishes
Indoor
81 01 04 35 01 FF
Outdoor
81 01 04 35 02 FF
One Push WB
81 01 04 35 03 FF
ATW
81 01 04 35 04 FF
Manual
81 01 04 35 05 FF
Manual Control mode
One Push Trigger
81 01 04 10 05 FF
One Push WB Trigger
Reset
81 01 04 03 00 FF
Manual Control of
R Gain
Up
81 01 04 03 02 FF
Down
81 01 04 03 03 FF
Direct
81 01 04 43 00 00 0p 0q FF
Lens
Indoor Mode
Outdoor Mode
CAM_RGain
pqrs: Zoom Position
tuvw: Focus Position
CAM_Initialize
Lens Initialization
Start
CAM_WB
Normal Auto
One Push WB Mode
Auto Tracing White
Balance
pq: R Gain
Command Set
Command
Command Packet
Comments
CAM_BGain
Reset
81 01 04 04 00 FF
81 01 04 04 02 FF
Down
81 01 04 04 03 FF
Direct
81 01 04 44 00 00 0p 0q FF
Full Auto
81 01 04 39 00 FF
Manual
81 01 04 039 03 FF
Shutter Priority
81 01 04 39 0A FF
Iris Priority
81 01 04 39 0B FF
Bright
81 01 04 039 0D FF
Bright mode
(Manual Control)
Auto
81 01 04 5A 02 FF
Auto Slow Shutter
On/Off
a)
Manual
81 01 04 5A 03 FF
Up
Automatic Exposure
Mode
Manual Control Mode
CAM_SlowShutter
Manual Control of
B Gain
pq: B Gain
Shutter Priority
Automatic Exposure
mode
Iris priority Automatic
Exposure mode
CAM_AE
CAM_Shutter
Reset
81 01 04 0A 00 FF
81 01 04 0A 02 FF
Down
81 01 04 0A 03 FF
Direct
81 01 04 4A 00 00 0p 0q FF
Up
Shutter Setting a)
pq: Shutter Position
Reset
Down
Direct
Up
CAM_Iris
81 01 04 0B 00 FF
Iris Setting
81 01 04 0B 02 FF
81 01 04 0B 03 FF
81 01 04 4B 00 00 0p 0q FF pq: Iris Position
a) Some models do not support slow shutter.
CAM _AF Mode
Normal AF
81 01 04 57 00 FF
Interval AF
81 01 04 57 01 FF
Zoom Trigger AF
81 01 04 57 02 FF
AF Movement Mode
Active/Interval Time 81 01 04 27 0p 0q 0r 0s FF
pq: Movement Time
rs: Interval
