Triple video output amplifier
9. Characteristics
Table 5: Characteristics
Operating range: T
j
=
−
20
°
C to +150
°
C; V
DD
= 180 V to 210 V; test conditions: T
amb
= 25
°
C; V
DD
= 200 V;
V
oc(1)
= V
oc(2)
= V
oc(3)
= 1 ⁄
2
V
DD
; C
L
= 10 pF (C
L
consists of parasitic and cathode capacitance); R
th(h-a)
= 18 K/W; measured in
test circuit of Figure 9 ; unless otherwise specified.
Symbol Parameter Conditions Min Typ Max Unit
I
q
quiescent supply current 5.6 6 7.6 mA
V
ref(int)
internal reference voltage (input
stage) - 2.5 - V
R
i
input resistance - 2.1 - k
Ω
G gain of amplifier 73 81 89
∆
G gain difference
−
4.2 0 +4.2
PSRR power supply rejection ratio f < 50 kHz [1] - 55 - dB
α
ct(DC)
DC crosstalk between channels -
−
50 - dB
Measurement output pin I
om
; V
oc
= V
oc(min)
to V
oc(max)
I
om(offset)
offset current of measurement
output (for three channels) I
oc
= 0
µ
A;
V
om
= 1.8 V to 6 V
−
50 - +50
µ
A
∆
I
om
/
∆
I
oc
linearity of current transfer
(for three channels) I
oc
=
−
100
µ
A to +100
µ
A;
V
om
= 1.8 V to 6 V
−
0.9
−
1.0
−
1.1
I
oc
=
−
100
µ
A to +10 mA;
V
om
= 1.8 V to 4 V
−
0.9
−
1.0
−
1.1
Output pins V
oc(1)
, V
oc(2)
, V
oc(3)
V
oc(DC)
DC output voltage I
i
= 0
µ
A 76 87 97 V
∆
V
oc(DC)(offset)
differential DC output offset
voltage between two output pins I
i
= 0
µ
A
−
5 0 +5 V
∆
V
oc(T)
output voltage temperature drift - 10 - mV/K
∆
V
oc(T)(offset)
differential output offset voltage
temperature drift between two
output pins - 0 - mV/K
I
oc(max)
maximum peak output current V
oc
= 50 V to V
DD
−
50 V - 20 - mA
V
oc(min)
minimum output voltage V
i
= 4.5 V; at I
oc
= 0 mA [2] - - 10 V
V
oc(max)
maximum output voltage V
i
= 0.5 V; at I
oc
= 0 mA [2] V
DD
−
15 - - V
B
S
small signal bandwidth V
oc
= 60 V (p-p) - 5.5 - MHz
B
L
large signal bandwidth V
oc
= 100 V (p-p) - 4.5 - MHz
t
co(p)
cathode output propagation time
50 % input to 50 % output V
oc
= 100 V (p-p) square
wave
[3] - 60 - ns
∆
t
co(p)
difference in cathode output
propagation time 50 % input to
50 % output (between two
output pins) V
oc
= 100 V (p-p) square
wave
[3] −
10 0 +10 ns
t
oc(r)
cathode output rise time
10 % output to 90 % output V
oc
= 50 V to 150 V square
wave
[3] 67 91 113 ns
t
oc(f)
cathode output fall time
90 % output to 10 % output V
oc
= 150 V to 50 V square
wave
[3] 67 91 113 ns
