1.
General description
The TDA8559T is a stereo amplifier that operates over a wide supply voltage range from
1.9 V to 30 V and consumes a very low quiescent current. This makes it suitable for
battery fed applications (2
×
1.5 V cells). Because of an internal voltage buffer, this device
can be used with or without a capacitor connected in series with the load. It can be
applied as a headphone amplifier, but also as a mono amplifier with a small speaker
(25
Ω
), or as a line driver in mains applications.
2.
Features
■
Operating voltage from 1.9 V to 30 V
■
Very low quiescent current
■
Low distortion
■
Few external components
■
Differential inputs
■
Usable as a mono amplifier in Bridge-Tied Load (BTL) or stereo Single-Ended (SE)
■
Single-ended mode without loudspeaker capacitor
■
Mute and Standby mode
■
Short-circuit proof to ground, to supply voltage (< 10 V) and across load
■
No switch on or switch off clicks
■
ESD protected on all pins
3.
Applications
■
Portable telephones
■
MP3 players
■
Portable audio
■
Mains fed equipment
TDA8559T
Low-voltage stereo headphone amplifier
Rev. 03 — 15 May 2006
Product data sheets
Document Outline
- 1. General description
- 2. Features
- 3. Applications
- 4. Quick reference data
- 5. Ordering information
- 6. Block diagram
- 7. Pinning information
- 8. Functional description
- 9. Internal circuitry
- 10. Limiting values
- 11. Thermal characteristics
- 12. Characteristics
- 13. Application information
- 13.1 General
- 13.2 Heatsink design
- 13.3 Test conditions
- 13.4 Input configurations
- 13.5 Standby/mute
- 13.6 Application1: SE with loudspeaker capacitor
- 13.7 Application2: SE to buffer (without loudspeaker capacitor)
- 13.8 Application3: Improved SE to buffer (without loudspeaker capacitor)
- 13.9 Application4: Bridge tied load mono amplifier
- 13.10 Application5: Line driver application
- 13.11 Application6: Line driver application
- 13.12 Application7: Line driver application
- 13.13 Application diagrams
- 13.14 Printed-circuit board layout
- 13.15 Response curves for low input mode
- 13.16 Response curves for high input mode
- 14. Test information
- 15. Package outline
- 16. Soldering
- 17. Revision history
- 18. Legal information
- 19. Contact information
- 20. Contents
