9397 750 14728
© Koninklijke Philips Electronics N.V. 2005. All rights reserved.
Product data sheet
Rev. 02 — 28 April 2005
4 of 16
Philips Semiconductors
TDA6107AJF
Triple video output amplifier
6.
Internal circuitry
7.
Limiting values
(1) All pins have an energy protection for positive or negative overstress situations.
Fig 3.
Internal pin configuration
7, 8, 9
mce458
esd
6.8 V
esd
esd
GND
V
DD
esd
from
input
circuit
from
input
circuit
from
control
circuit
from black-
current
measurement
circuit
from
control
circuit
to black-current
measurement circuit
to black-current
measurement circuit
to black-current
measurement circuit
to black-current
measurement circuit
esd
TDA6107AJF
(1)
esd
flash
to cascode
stage
1, 2, 3
4
6
5
Vbias
Table 3:
Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134). Voltages measured with respect to ground; currents
as specified in
Symbol
Parameter
Conditions
Min
Max
Unit
V
DD
supply voltage
0
250
V
V
i
input voltage at pins V
i(1)
, V
i(2)
and V
i(3)
0
12
V
V
om
measurement output voltage
0
6
V
|I
om(mean)
|
absolute value of mean current of
measurement output (for three channels)
V
oc
= 0 V to V
DD
;
V
om
= 1.8 V to 6 V
-
5.6
mA
V
oc
cathode output voltage
0
V
DD
V
T
stg
storage temperature
−
55
+150
°
C
T
j
junction temperature
−
20
+150
°
C
V
esd
electrostatic discharge voltage
Human Body Model (HBM)
-
±
3000
V
Machine Model (MM)
-
±
300
V
