Appendix A Specification
Model BT-510U BT-520U
Bluetooth Spec.
Compliance
Bluetooth V2.0+EDR
Transfer rates
(Max)
Max UART baud rates of 3Mbps
Operating
Voltage
+5V
USB Standard USB 2.0
Operating
Distance
100 m in free space 10 m in free space
Antenna 2dBi Antenna 0 dBi printing Antenna
Dimension 49.36 (L) x 17.99(W) x 7.55(H) mm
Power
Consumption
TX Æ 120mA
RX Æ 58mA
Stand By Æ 50mA TX Æ 60mA
RX Æ 58mA
Stand By Æ 30mA
Environment
Operation temperature: 0 ~ 60 Degree C
Storage temperature: -10 ~ 70 Degree C
Humidity: 5 ~ 90% non-condensing
Radio
Spread
Spectrum
Frequency Hopping Spread Spectrum (FHSS)
Frequency
Range
2402~2483.5MHz
RF Channels 79
Polarization Omni-directional
Modulation GFSK for 1Mbps, 4-DQPSK for 2Mbps, 8-DPSK for 3Mbps
Output Power 13.35dBm 1.74dBm
Receiver
Sensitivity <-82dBm at < 0.1%
BER
<-82dBm at < 0.1% BER
Base Band
Support of ACL link with data rate up to 3Mbps
Physical Links
Support of SCO link
Network
Capabilities Support of piconet point-to-point and point-to-multipoint
connections
