Connecting your equipment 03
26
En
Connecting an HDD/DVD recorder, BD recorder and other video sources
This receiver has two sets of audio/video inputs and outputs suitable for connecting analog or digital video devices,
including HDD/DVD recorders and BD recorders.
When you set up the receiver you’ll need to tell the receiver which input you connected the recorder to (see also The
Input Setup menu on page 37).
• In order to record, you must connect the analog
audio cables (the digital connection is for playback
only) (page 59).
• If your HDD/DVD recorder, BD recorder, etc., is
equipped with an HDMI output terminal, we
recommend connecting it to the receiver’s HDMI IN
terminal. When doing so, also connect the receiver
and TV by HDMI (see Connecting using HDMI on
page 23).
RS-232C
HDMI
SPEAKERS
ASSIGNABLE
COAXIAL COMPONENT VIDEO ASSIGNABLE OPTICAL
ASSIGNABLE ASSIGNABLE
MONITOR
OUT
IN
Y
P R Y
CD-R/TAPE
ANTENNA
FM UNBAL 75 AM LOOP
IN
CD
VIDEO
MONITOR
AUDIO
IN OUT
OUT
ZONE2
OUT
DVD
IN
TV/SAT
IN
VIDEO
IN
DVR/BDR
OUT IN
P B
P R P B
1
IN BD
IN 1
IN
2
IN
3
OUT
A R L R L R SURROUND BACK SURROUND CENTER FRONT
1 4
(DVD)
IN 1
(DVD)
IN 1
(TV/SAT)
IN 2
(DVR/BDR)
IN
FRONT CENTER SURROUND SURR
(VID
IN 2
(CD)
IN 2
(DVR/BDR)
CONTROL
EXTENSION
IN
IN
OUT
OUT
SUBWOOFER
IN
4 LAN (10/100)
(OUTPUT
5 V
150 mA
MAX)
SIRIUS
IN
Class 2 Wiring
IR
DIGITAL OUT
COAXIAL OPTICAL ANALOG R L ANALOG R L
AUDIO OUT AUDIO IN VIDEO OUT
VIDEO VIDEO
VIDEO IN
HDD/DVD recorder, BD recorder, etc.
Select one
