5
This VCR is designed to send picture and sound
signal on UHF channel E36 (between E28 to E60) to
the TV, through the RF coaxial cable.
1 Make sure the VCR is turned off and no cassette
is inserted.
2 Press STOP/EJECT 7 / 0
on the front panel for
more than 5 seconds. All four indicators on the
display window will blink.
3 Press PLAY
5 or
STOP
∞
on the remote control
to select the TV system.
The indicators represent the TV system as de-
scribed in the table below.
4 Press OK/STATUS .
5 Turn on the TV, and tune it to UHF channel E36.
• If two vertical white bars appear clearly on the TV
screen, press OK/STATUS and go to step 6.
• If the two vertical white bars do not appear clearly,
press PLAY 5 or STOP ∞ on the remote control to
set the video channel to any vacant channel be-
tween channel 28 to 60.
• The indicators tell channel position. The indicators
light and blink at different speed by the channel
position as shown in the table in the next column.The
POWER indicator blinks and the
REC indicator
lights up regardless of the channel number.
6 Press OK/STATUS .
The CASS and TIMER indicator will turn off.
You will now enter the Language Setting mode
explained on the next column.
POWER CASS REC TIMER
Setting the Video Channel
System
Country
China, Russia,
Hong Kong, South
B/G
D/K
I
West Europe, ASEAN
countries, New Zealand
Africa, United Kingdom
TV
East Europe
POWER
blink blink blink
CASS REC TIMER
Indicator
blink
blink blink blink
blink blink
off
off off
Test signal
(two vertical white bars)
For the first time you turn on this VCR, some basic
settings must be done first before going on to
further operations.
❍
Select the Language
1 Press POWER .
The language selection screen
appears.
2 Press PLAY
5 or
STOP
∞
to select either "ENGLISH",
or "
" (Chinese).
3 Press OK/STATUS .
1
Before operating the VCR, be familiar with the
menu operations first because most of the features
built into the VCR can be available only on the
menus.
1 Press MENU to display the main menu screen.
2 Press PLAY
5 or
STOP
∞ to select a desired
feature on the menu, then press OK / STATUS.
3 When you select a feature, go to the section in
this manual and follow the instructions described
there.
To go back to the previous menu screen, press
REW 2. To change the setting of a menu item,
press FF 3. Press MENU to exit.
To watch a picture from this VCR on the TV,
select the same channel you have selected as the
video channel on the TV.
Note:
If you use only external video input (AV) mode to watch
the picture from this VCR, you can turn off the video
channel output. To turn off the video output channel, press
VCR CH ∞
until CASS and TIMER indicators on the
display window are off.
Menu Operations
Initial Set Up
ENGLISH
SELECT: CONFIRM: OK
END: MENU
S S etting U U p
CHANNEL
CASS TIMER
Blinking Speed
light
light
light
blink
blink
blink
light light
light
light
blink
blink
60
40
50
36
30
28
51 - 59
41 - 49
37 - 39
31 - 35
29
fast
fast
slow
slow
indicator indicator
